Features and Controls

Make sure that the callout letters in Figure 2 agree with the
features and controls in the table that follows.
2

Snow Thrower Features and Controls

A Fuel Shut-Off Valve (if equipped)
B Throttle Control (if equipped)
C ON / OFF Switch
D Choke CLOSED / Choke OPEN
E Primer Button
F Alternate Choke-Prime Instructions
G
Auger Control Lever
H Speed Control Lever
I Chute and Deflector Control Switch (if equipped)
J Traction Control Lever
K Grip Warmer Switch (if equipped)
L Clean-Out Tool
M
Skid Shoes
N
---- Headlight (if equipped)
5
