Use The Steering Control Feature; Clean A Clogged Discharge Chute; Headlight; Use The Heated Hand Grips - Simplicity Signature Series Operator's Manual

11

Use the Steering Control Feature

The steering control feature helps the operator turn the
unit. The steering control temporarily disengages one drive
wheel while the other continues to drive through a turn.
1. Engage the traction control lever (F, Figure 11) to move
the machine forward.
2. Lift and hold the left steering control trigger (P) to turn left.
3. Release the left trigger, to continue straight.
4. Lift and hold the right steering control trigger (P), to turn
right.
5. Release the right trigger, to continue straight.
12

Clean a Clogged Discharge Chute

DANGER
The rotating impeller in the discharge chute throws snow.
Fingers can quickly become caught in the impeller and
result in traumatic amputation or severe laceration. DO NOT
use your hands to clean a clogged discharge chute! Always
use a clean-out tool.
1. STOP the engine. Remove the ignition key or push/pull
key.
2. Make sure that the impeller does not rotate.
3. Rotate chute guard out of the way and use a clean-out
tool (G, Figure 13) to remove snow from the discharge
chute. DO NOT use your hands to clean a clogged
discharge chute!
13

Headlight

Some models are equipped with a headlight that illuminates
the area in front of the snowthrower. When you START the
engine, the headlight turns ON. There is no switch.

Use the Heated Hand Grips

1. Turn on the grip warmer switch (A, Figure 14) to activate
the heated hand grips. The button LED back-light will
illuminate
2. Turn OFF the grip warmer switch before you stop the
snowthrower.
14

Maintenance and Adjustments

We recommend you contact an Authorized Service Dealer for
all maintenance, adjustments, and servicing of the unit. The
owner can do some routine maintenance tasks. Refer to the
maintenance schedule and procedures that follow.
11
