Simplicity Snower Thrower Illustrated Parts List

Simplicity Snower Thrower Illustrated Parts List

Attachment
Hide thumbs
Table of Contents

Advertisement

Quick Links

Attachment
Illustrated

Parts List

Attachment
Mfg. No.
Description
1694404
47" Two Stage Snower Thrower
MANUFACTURING, INC.
500 N. Spring Street / PO Box 997
Port Washington, WI 53074-0997 USA
www.simplicitymfg.com
© Copyright
2003
Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.
11/2003
Rev.
TP 400-3880-00-AT-SMAN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Snower Thrower and is the answer not in the manual?

Questions and answers

Владислав
January 29, 2025

У Вас можно заказать кнопку снегоуборщика SIMPLISITY L 1528 EX. № 1754865 YP. если нужно скину фото.

0

Related Manuals for Simplicity Snower Thrower

Summary of Contents for Simplicity Snower Thrower

  • Page 1: Parts List

    Attachment Illustrated Parts List Attachment Mfg. No. Description 1694404 47" Two Stage Snower Thrower MANUFACTURING, INC. 500 N. Spring Street / PO Box 997 Port Washington, WI 53074-0997 USA www.simplicitymfg.com © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. Printed In USA.
  • Page 2 Auger Gearbox & Shaft NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-3880-00-AT-SMAN G985784...
  • Page 3 Auger Gearbox & Shaft REF NO. PART NO. QTY. 1917372 1917356 1725611 1709669 1709673 1709663 1709635 1709668 1709672 1709676 1709670 1709671 1921719 1709665 1668971 1720487 1921977 1709675 1709666 1709667 1709674 1720368 1721781 Footnotes The above parts group applies to the following Mfg. Nos.: 1694404 - 47"...
  • Page 4 Auger Group 985784 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. Assemble with ends up The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage TP 400-3880-00-AT-SMAN © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 5 Auger Group REF NO. PART NO. QTY. 1960282 1917356 1917372 921133 1709679 1721780 1709678 172279 173934 1919326 1960282 1921719 1918265 1922127 1721757 1916622 1916964 1709681 1921960 1709683 1931335 1720248 Footnotes The above parts group applies to the following Mfg. Nos.: 1694404 - 47"...

  • Page 6: Decals Group

    Decals Group 986389 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage TP 400-3880-00-AT-SMAN © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 7 Decals Group REF NO. PART NO. QTY. 1722674 1716531 1716532 1709688 1709689 1722093 1716540 Footnotes The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION DECAL, OPEI (Not Serviced) DECAL, Danger, Blower DECAL, Caution...

  • Page 8: Front Pto Group

    Front PTO Group 986353 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage TP 400-3880-00-AT-SMAN © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 9 Front PTO Group REF NO. PART NO. QTY. 1931335 1715419 1725257 1919438 1933260 1725023 1685480 1709350 1679003 1725451 1725452 Footnotes The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION CARRIAGE BOLT, 5/16-18 x 1 BALL BEARING W/FLANGE...
  • Page 10 Housing & Chain Case Group 986388 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage TP 400-3880-00-AT-SMAN © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 11 Housing & Chain Case Group REF NO. PART NO. QTY. 1718837 1679003 1709350 1718838 1709355 1709352 1716877 1709348 1960506 922138 1930540 1923358 1931334 172279 173934 172278 1664847 1674020 1725461 1917356 1917372 1721766 1725462 960208 1721769 1721767 1930544 1721763 1709624 1665696 108202 1725460 1933988...
  • Page 12 Skid Shoe Group 986390 NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage TP 400-3880-00-AT-SMAN © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved.
  • Page 13 Skid Shoe Group REF NO. PART NO. QTY. 1960223 1709656 1924874 1917356 1917372 1924366 1709660 1960587 1709659 1709658 1923362 1931333 Footnotes The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. DESCRIPTION CARRIAGE BOLT, 5/16-18 x 1-1/4 SKID SHOE, Snowthrower...

  • Page 14: Spout Group

    Spout Group NOTE: Unless noted otherwise, use the standard hardware torque specification chart. The above parts group applies to the following Mfg. Nos.: 1694404 - 47" Two Stage © Copyright 2003 Simplicity Manufacturing, Inc. All Rights Reserved. TP 400-3880-00-AT-SMAN 986387...
  • Page 15 Spout Group REF NO. PART NO. QTY. 1702219 1921319 1960126 1611945 1611939 1721601 1923358 1724604 1925003 1717481 1725464 1923341 1924009 1930547 1721617 1701011 1916622 1916964 1960151 1668344 1960221 1705920 1721590 1717482 1715885 1717483 1666613 1717477 1704446 1960683 1931333 960210 1919326 1919438 1715799 Footnotes...

  • Page 16: Hardware Identification & Torque Specifications

    Hardware Identification & Torque Specifications Common Hardware Types Hex Head Capscrew Carriage Bolt Standard Hardware Sizing When a washer or nut is identified as 1/2”, this is the Nominal size , meaning the inside diameter is 1/2 inch; if a second number is present it represent the threads per inch When bolt or capscrew is identified as 1/2 - 16 x 2”, this means the Nominal size , or body diameter is 1/2 inch;...
