Replace The Scraper Bar; Checking Tire Pressure; Storage; Storage - Fuel System - Simplicity Signature Series Operator's Manual

29
6. Turn the adjuster clockwise or counterclockwise to get
a small amount of play in the lever before the steering
control operates.
7. Use a wrench to hold stationary the adjuster tube. Use
another wrench to tighten the jam nut.
8. Lower the adjuster cover onto the adjuster.
9. Do the same procedure for the other steering control
cable.
10. Test 1 - Left Side Steering Control
Lift and hold the left steering control trigger. The wheel
should roll freely. When the trigger is released, the wheel
should top.
11. Test 2 - Right Side Steering Control
Lift and hold the right steering control trigger. The wheel
should roll freely. When the trigger is released the wheel
should stop.
30
18

Replace the Scraper Bar

DANGER
The snowthrower contains a rotating auger and impeller
that throws snow. Fingers or feet can quickly become
caught in the rotating auger or impeller resulting in traumatic
amputation or severe laceration.
• STOP the engine, wait for all moving parts to stop,
and remove the ignition key or push/pull key before
maintenance or repairs.
The scraper bar will gradually wear and need replacement.
1. Turn the engine OFF and remove the ignition key or
push/pull key.
2. Loosen the retaining nuts (A, Figure 31) and bolts (B) and
remove the scraper bar (C).
3. Align the holes in the new scraper bar with the holes on
the auger housing.
4. Tighten the retaining nuts and bolts with your
hands. Then, loosen the skid shoes
5. Tighten the retaining nuts and bolts.
6. Check the clearance between the scraper bar and the
surface.
7. Adjust the skid shoes to keep the ground clearance for
the type of surface being cleared. See Adjust the Skid
Shoe Height.
31

Checking Tire Pressure

Tire pressure should be checked periodically. Recommended
tire pressure varies by tire manufacturer. A good rule of
thumb is to inflate the tire up to, but not exceeding, the "Max
Inflation" stamped on the sidewall of the tire.

Storage

Storage - Fuel System

Fuel can become stale when kept in a storage container for
more than 30 days. Each time you fill the container with fuel,
®
add STA-BIL 360° PROTECTION™ to the fuel as specified
by the manufacturer's instructions. This keeps fuel fresh and
decreases fuel-related problems or contamination in the fuel
system.
It is not necessary to drain fuel from the engine when STA-
®
BIL 360° PROTECTION™ is added as instructed. Before
