6 .6 - MAINTENANCE AND PERIODIC INSPECTIONS ALH AND ALHS SERIES
1 Pump hose replacement.
2 Lubricant replacement.
3 Gearbox oil replacement.
4 Replacement of the seal ring (REF 27).
5 Replacement of the shaft seal (REF 26).
Replacement of the shaft seal (REF 105)
6
and (REF 106) (ALHS series).
7 Replacement of the shoes.
8 Replacement of the cover seal (REF 10).
8 Replacement of the sleeves (REF 6).
Replacement of the bearings (REF 103)
9
and (REF 104) (ALHS series)
9 Check the lubricant level.
Check for lubricant leakage at the leakage
10
channel.
Check the pump casing to discern possi-
11 ble leakages around the cover, the sight
glass, the flanges and the sleeves.
Check for wear on the shoe's pressing
12
surface.
Check the presence of a gearbox oil leak-
13
age.
Check for strange noises coming from the
14 pump, gearbox and bearing case or ab-
normal pump casing temperature.
22 albinpump@irco.com Albinpump.com

Preventative maintenance suggests chang-
ing the pump hose after 90% of the life
time of the first hose.
At the end of 2 hose changes or 5000
hours run time, unless there is a hose
rupture (replace immediately).
Refer to the gearbox maintenance manual
provided with the pump.
In case of presence of lubricant in the leak
channel.
In case of presence of lubricant in the leak
channel.
In case of presence of oil in the leak chan-
nel or at the lip seals.
The contact surface of a shoe should
be flat. Replace if the contact surface is
concave.
In the case of a leak around the pump
cover.
If these are damaged.
If there are abnormal noises coming from
the bearing case.
Before starting the pump and periodically
during the pump service.
Before starting the pump and periodically
during the pump service.
Before starting the pump and periodically
during the pump service.
At every hose change.
Before starting the pump and periodically
during the pump service.
Periodically during the pump service.
Albin Pump ALH Instruction Manual

see §6.3
see §6.1
see §6.4.2
see §6.4.2
see §6.4.2 and §6.6
see §6.4.1
see §6.3.2
Refer to §6.3 Perform operations
1, 2, 3 and 4 of §6.3.1 and change
sleeves. Respect directives of
security.
see §6.4 and §6.6
see §6.1
see §6.4
see §6.4
see §3.5
