Opening Dimensions; Dual Installation - Subzero UC-24R Design Manual

Undercounter Refrigeration

Opening Dimensions

UNDERCOUNTER MODELS
24"
OPENING
1
34 /
2
(876)
OPENING
HEIGHT
SIDE VIEW
1
NOTE: 3 / " finished returns will be visible and should be finished to match cabinetry.
2 (89)
3
/ "
4 (19)
TYPICAL
1
3 / "
2 (89)
FINISHED
RETURN
W
FRAMELESS
CABINETRY
OPENING WIDTH
24" Model
DUAL OPENING WIDTH
Two 24" Models
Dual installation kit required.
(610)
DEPTH
TOP VIEW
" W
OPENING WIDTH
FRONT VIEW
3
/ "
4 (19)
TYPICAL
1
3 / "
2 (89)
FINISHED FILLER
RETURN
W
FRAMED
CABINETRY
24"
48 1/8"

DUAL INSTALLATION

If two units are installed side by side, a dual installation kit
may be required. Installations without a custom filler strip
require a dual installation kit. If a dual installation kit is not
specified, a 2"
(51)
units. Dual installations without a filler strip can only be
accomplished using two units with opposite hinges. Refer
to the illustrations below.
Dual installation kits are available through an authorized
Sub-Zero dealer. For local dealer information, visit the
find a showroom section of our website, subzero.com.
For questions regarding the installation, call Sub-Zero
Customer Care at 800-222-7820.
WITHOUT FILLER STRIP
Opposite hinges
W
(610)
W
(1222)
filler strip is recommended between the
FILLER STRIP
Same side hinges
subzero.com | 5
