- Page 1 800.222.7820 UC Series Service Manual UC-24C Component Access & Removal...
- Page 2 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) MODEL UC-24C MODEL UC-24C EXTERIOR COSMETIC AND MECHANICAL COMPONENTS Kickplate (Model UC-24C) To remove the kickplate, extract the mounting screws Mounting Screw located at each end of the kickplate and pull the kick- (1 of 2) plate forward.
- Page 3 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Door Shelf Components (Model UC-24C) Retainer Clips The door shelf retainer fits into notches in the retainer clips that are attached to the door dikes with screws. To remove the door shelf components (See Figure 7- 32): 1.
- Page 4 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) MODEL UC-24C INTERIOR COSMETIC AND MECHANICAL COMPONENTS Wine Rack Assembly (Model UC-24C) To remove a wine rack assembly (See Figure 7-34): 1. Pull rack forward until it stops. 2. Lift front of rack up while continuing to pull forward. 3.
- Page 5 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Ice Bucket (Model UC-24C) To remove the ice bucket, grab the handle that is mold- ed into the bottom front of the bucket and pull bucket forward (See Figure 7-37). Ice Bucket Refrigerator Liner Cover (Model UC-24C) Screws pass though the refrigerator liner cover into the...
- Page 6 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Shelf Ladders (Model UC-24C) The shelf ladders are attached to the side walls with screws. To remove a shelf ladder, first remove the refrigerator liner cover. Then, extract the shelf ladder mounting screws and pull the shelf ladder away from side wall and out of compartment.
- Page 7 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Icemaker Assembly (Model UC-24C) The icemaker assembly is attached to the right side of Screws the evaporator cover with screws, two at the top of the icemaker and one at the bottom. To remove the icemaker assembly, (See Figure 7-43): 1.
- Page 8 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Defrost Terminator (Model UC-24C) The defrost terminator is attached to the evaporator out- Defrost Terminator let. To remove the defrost terminator, the mullion assembly must be removed first, then (See Figures 7-46): 1.
- Page 9 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Evaporator Fan Assembly (Model UC-24C) Evaporator Fan Assembly Screws pass through the rear bracket of the evaporator fan assembly, as well as the baffle control assembly, into screw grommet/stand-offs to secure the fan assembly the back wall.
- Page 10 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) MODEL UC-24C UNIT TRAY MECHANICAL COMPONENTS Main Control Board Assembly (Model UC-24C) The control board assembly sits at the front left side of the unit tray, held in place with dual-lock fasteners, which is similar to velcro.
- Page 11 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Water Valve (Model UC-24C) The quick-connect water valve is attached to a flange that is part of an air baffle that is attached to the unit tray. NOTE: To remove the water valve, the appliance must be pulled from its installation.
- Page 12 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) MODEL UC-24C SEALED SYSTEM COMPONENTS NOTE: To remove any sealed system component from an Under Counter appliance, the appliance must be pulled from its installation. When removing an Under Counter appliance from its installation, keep in mind that an anti-tip bracket and a countertop bracket may have been used to make a solid installation.
- Page 13 Component Removal UNDER COUNTER SERIES UNDER COUNTER SERIES (SWS #3603000) (SWS #3603000) Evaporator (Model UC-24C) The evaporator is attached to the rear wall with screws, behind the evaporator cover. To Remove the evaporator (See Figures 7-59): 1. Extract screws which hold evaporator to rear wall. 2.
