- Page 1 Installation and Maintenance Manual RPLI BARCODE 19.03 - 6180341_04 TRANSLATION FROM ORIGINAL...
- Page 3 Dear customer, Thank you for choosing an AERMEC product. It is the fruit of many years of experience and special design studies and has been made of the highest grade materials and with cutting edge technology. The quality level is being constantly monitored, so AERMEC products are synonymous with Safety, Quality and Reliability.
-
Page 4: Table Of Contents
INDEX IDENTIFICATION OF THE UNIT ..........................................6 GENERAL STANDARDS ............................................... 7 OPERATIONAL LIMITS..............................................8 RECEPTION, HANDLING AND STORAGE ........................................8 INSTALLATION CLEARANCES ............................................. 9 CEILING FIXTURE DIAGRAM ............................................. 9 WATER COILS ................................................11 DIAMETER OF THE HYDRAULIC CONNECTIONS ....................................12 AERAULIC CONNECTIONS ............................................ -
Page 6: Identification Of The Unit
Furthermore, each package comes with its own plate featuring the weight and other useful traceability information. RATED DATA The units are fitted with adhesive plates summarising the main technical specifications. CONFIGURATOR Field Code 1,2,3,4 RPLI 5,6,7 Size 030-050-070-100-140-200-300-400 Version Low useful stati pressure High useful stati pressure Installation °... -
Page 7: General Standards
GENERAL STANDARDS The units were built in accordance with the technological standards and safety legislation in force. All the precautions given in this manual must be observed to avoid damage to property and harm to people. Any faults must be repaired promptly by qualified personnel. -
Page 8: Operational Limits
OPERATIONAL LIMITS Correct operation is not assured following fires, high winds, earthquake and other natural phenomena of exceptional intensity. If the unit is used in an aggressive atmosphere and/or with aggressive water, please consult with the head office. In the event of proximity to the sea or ocean, the impact of salty air must be taken into account when selecting the unit. -
Page 9: Installation Clearances
RPLI-100-W/E Il presente disegno è di esclusiva proprietà di AERMEC S.p.A. e non può essere copiato, riprodotto o consegnato a terzi senza la autorizzazione di AERMEC stessa / This drawing is exclusive property of AERMEC S.p.A. and it is forbidden to copy, print or give... - Page 10 CONNECTION OF ACCESSORY MODULES Connect as follows: SIZES 030-100: 1) Locate the mouth of the unit on which the module will be fixed; 2) Apply a sealing gasket around the perimeter where the module will be brought in contact with the base unit; 3) Place the accessory module against the base unit, aligning it with the mouth;...
-
Page 11: Water Coils
HYDRAULIC CONNECTIONS CONDENSATE DRAIN Negative pressure systems: H1 = 2P An adequate drain system must have a siphon in order to: H2 = H1/2 • allow free condensation draining; • prevent the entry of air into the depression systems; Pressure systems: •... -
Page 12: Diameter Of The Hydraulic Connections
DIAMETER OF THE HYDRAULIC CONNECTIONS INTERNAL COIL (W) EXTERNAL PROMISCUOUS COIL (MBF and MBF_X) EXTERNAL POST HEATING COIL (MBP) Type Ø M coil inlet Ø M coil outlet Ø M conden- Type Ø M coil inlet Ø M coil outlet Ø... -
Page 13: Unit Dimensions - Type 1 Orientation Standard
RPLI 030 - 050 Weight kg 030-050 L 95-93 030-050 P 030-050 LW 99-97 ... - Page 14 160/160 Il presente disegno è di esclusiva proprietà di AERMEC S.p.A. e non può essere copiato, riprodotto o consegnato a terzi senza la autorizzazione di AERMEC stessa / This drawing is exclusive property of AERMEC S.p.A. and it is forbidden to copy, print or give...
- Page 15 300 L/300 P 287/280 Il presente disegno è di esclusiva proprietà di AERMEC S.p.A. e non può essere copiato, riprodotto o consegnato a terzi senza la autorizzazione di AERMEC stessa / This drawing is exclusive property of AERMEC S.p.A. and it is forbidden to copy, print or give ...
- Page 16 RPLI 400 Il presente disegno è di esclusiva proprietà di AERMEC S.p.A. e non può essere copiato, riprodotto o consegnato a terzi senza la autorizzazione di AERMEC stessa / This drawing is exclusive property of AERMEC S.p.A. and it is forbidden to copy, print or give...
-
Page 17: Unit Dimensions - Type 2 Orientation (To Be Requested During Order)
Electric Coil Water Outlet Ø 1/2” Inspections Side W / E OPTIONAL Connections Side Rear Side Hot/Cold H2O Coil (Optional) Electric Coil (Optional) RPLI 030 - 050 Weight kg 030-050 L 95-93 030-050 P 030-050 LW 99-97 Emissione / Issue... - Page 18 160/160 Il presente disegno è di esclusiva proprietà di AERMEC S.p.A. e non può essere copiato, riprodotto o consegnato a terzi senza la autorizzazione di AERMEC stessa / This drawing is exclusive property of AERMEC S.p.A. and it is forbidden to copy, print or give...
- Page 19 UNI EN 22768 Il presente disegno è di esclusiva proprietà di AERMEC S.p.A. e non può essere copiato, riprodotto o consegnato a terzi senza la autorizzazione di AERMEC stessa / This drawing is exclusive property of AERMEC S.p.A. and it is forbidden to copy, print or give...
-
Page 20: Dismantling And Disposal
DISMANTLING AND DISPOSAL GENERAL STANDARDS All dismantling and waste disposal operations must be carried out by qualified personnel in compliance with national legislation in force in the country of use. DISMANTLING When dismantling the unit, comply with the following provisions: •... -
Page 21: Maintenance
MAINTENANCE Wear proper personal protective equipment (PPE) to perform maintenance. Before accessing the unit for maintenance and/or cleaning, make sure that it is not live, that it cannot be powered without the operator knowing it and that the heat exchange coils are not on. FILTERS Cleaning the filters is fundamental to keep the air quality in the room at a high standard. -
Page 22: Wiring Diagram
ABLUFT VENTILATOR VENTILATEUR SOUFFLAGE VENTILATEUR REPRISE VENTILATORE MANDATA VENTILATORE RIPRESA SUPPLY FAN EXHAUST FAN WIRING DIAGRAM LABEL - RPLI 050L - 070L -140L - 300L ET00055 rev.01 cod. 0660035 R3G225RE0703 cod. 0660033 R3G250RO40A1 cod. 0660034 R3G280RP54B1 ZULUFT VENTILATOR ABLUFT VENTILATOR... - Page 23 WIRING DIAGRAM LABEL - RPLI 400L ET00051 rev.02 ABLUFT VENTILATOR ZULUFT VENTILATOR VENTILATEUR REPRISE VENTILATEUR SOUFFLAGE VENTILATORE RIPRESA VENTILATORE MANDATA EXHAUST FAN SUPPLY FAN cod. 0660036 R3G355RG5601 POTENTIOMETER LABEL - FOR ALL THE SIZES Full Speed ET00056 rev.00 +10Vdc Signal 10V...
- Page 24 WIRING DIAGRAM LABEL - RPLI 030P - 050P - 070P - 100P - 140P - 200P ET00055 rev.01 cod. 0660035 R3G225RE0703 cod. 0660033 R3G250RO40A1 cod. 0660034 R3G280RP54B1 ZULUFT VENTILATOR ABLUFT VENTILATOR VENTILATEUR SOUFFLAGE VENTILATEUR REPRISE VENTILATORE MANDATA VENTILATORE RIPRESA SUPPLY FAN...
- Page 25 WIRING DIAGRAM LABEL - RPLI 400P ET00057 rev.01 ABLUFT VENTILATOR ZULUFT VENTILATOR VENTILATEUR REPRISE VENTILATEUR SOUFFLAGE VENTILATORE RIPRESA VENTILATORE MANDATA EXHAUST FAN SUPPLY FAN cod. 0660042 R3G355RJ7501 POTENTIOMETER LABEL - FOR ALL THE SIZES Full Speed ET00056 rev.00 +10Vdc Signal 10V...
- Page 28 Via Roma, 996 37040 Bevilacqua (VR) - Italia Tel. + 39 0442 633111 Fax +39 0442 93577 marketing@aermec.com www.aermec.com Aermec reserves the right to make all modification deemed necessary for improving the product at any time with any modification of technical data.
