WE-EF ETC330-GB Installation And Maintenance Instructions Manual
Inground luminaire
Hide thumbs
Also See for ETC330-GB:
Related Manuals for WE-EF ETC330-GB
Summary of Contents for WE-EF ETC330-GB
- Page 1 WE-EF LEUCHTEN Installation and Maintenance Instructions Inground Luminaire ETC330-GB LED ETC340-GB LED INSTALLER HOTLINE +61 458 933 399 7am – 7pm AEST...
- Page 3 Maintenance Warning: Do not open luminaire while mains supply is switched on. Apart from cleaning the outside of the luminaire, no special maintenance is necessary. Damaged mains supply cable: Contact your authorised WE-EF agent for replacement. Inground Luminaire ETC330-GB ETC340-GB...
- Page 4 Fig. I Minimum Distance ETC330-GB: No minimum distance. ETC340-GB: Ensure the minimum distance for objects to be illuminated is correct (see illustration - - - - - - inside luminaire).
- Page 5 Phase One Phase Two Blockout Installation Procedure Luminaire Installation, Electrical Connection, and (during earth or masonry work) Aiming Procedure 1) Ensure a suitable recess is provided to accommo- 5) Switch off mains electrical supply. date installation blockout/mounting ring assembly 6) Check that rating shown on luminaire label con- B/M.
- Page 6 13) Insert screw driver into a slot on locking wheel W. Rotate locking wheel W in the 'LOCK' direction until the gimbal is fi rmly secured (Fig. IV). Warning: Do not tighten more than necessary to secure gimbal. 14) Ensure that all surfaces are clean and dry. Reposition lens/gasket assembly Q, cover P and screws C on luminaire housing A.
- Page 7 ETC330-GB Fig. III...
- Page 8 ETC340-GB Fig. III...
- Page 9 Fig. IV Fig. V...
-
Page 10: Installation
NOTE: LED luminaires are static sensitive devices; please ensure that appropriate ESD measures are taken before opening luminaire. If in doubt, please contact WE-EF. The desiccant sachet MUST not be left in the open environment. please seal luminaire down within 15 minutes of opening sachet. - Page 12 Fax +1 724 742 0035 info.switzerland@we-ef.com info.usa@we-ef.com WE-EF LIGHTING United Kingdom Tel +44 844 880 5346 Fax +44 844 880 5347 info.uk@we-ef.com INSTALLER HOTLINE TO9128W0315 © WE-EF 2015 +61 458 933 399 7am – 7pm AEST Technical specifi cations are subject to change.
