SETUP, PARTS & MAINTENANCE
MANUAL EC CUTTERDECKS
Cutting Unit Models:
933506
Cutterdeck-36 Rear Discharge EC
933407
Cutterdeck-36 Side Discharge EC
(Operation & Safety Manual: 4115264, 4115265)
WARNING: If incorrectly used this machine can cause severe injury. Those who use
and maintain this machine should be trained in its proper use, warned of its dangers
and should read the entire manual before attempting to set up, operate, adjust or
service the machine.
4115263 REV B
Advertisement
Related Manuals for Textron RANSOMES 933506
Summary of Contents for Textron RANSOMES 933506
- Page 1 SETUP, PARTS & MAINTENANCE MANUAL EC CUTTERDECKS Cutting Unit Models: 933506 Cutterdeck-36 Rear Discharge EC 933407 Cutterdeck-36 Side Discharge EC (Operation & Safety Manual: 4115264, 4115265) WARNING: If incorrectly used this machine can cause severe injury. Those who use and maintain this machine should be trained in its proper use, warned of its dangers and should read the entire manual before attempting to set up, operate, adjust or service the machine.
- Page 2 © 2003, TEXTRON INC...
-
Page 3: Table Of Contents
You'll always be glad you did. Textron Golf, Turf & Specialty Products One Bob Cat Lane Johnson Creek, WI 53038-0469... -
Page 4: Safety
These words appear in this and approved by Textron Golf, Turf & Specialty manual and on the safety labels attached to Textron Products Engineering Department. Any Textron Golf, Turf & Specialty Products machines. For your Golf, Turf &... -
Page 5: Assembly/Set-Up Instructions
ASSEMBLY/SET-UP INSTRUCTIONS Midsize Decks FIXED CUTTERDECK ATTACHMENT 1. Remove the cutterdeck from the crate. 2. Unbolt the caster wheels and the shipping brackets from the crate. 3. Remove the shipping bracket from the caster wheel by loosening the caster bolt and sliding the shipping bracket off and retighten caster bolt. - Page 6 ASSEMBLY/SET-UP INSTRUCTIONS Midsize Decks 6. Remove belt cover and set aside. 7. Block the rear of the cutterdeck with the appropriate height block for the desired height of cut B. See Support Block Chart below. " 5 " 5 " 5 "...
- Page 7 PARTS SECTION Midsize Decks PARTS SECTION...
-
Page 8: 36" Ec Side Discharge Deck
36" EC SIDE DISCHARGE DECK Midsize Decks FIGURE 1... - Page 9 36" EC SIDE DISCHARGE DECK Midsize Decks FIGURE 1 4115263-01 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4115084 S-36 DECK SD W/LABS EC 2721323 S-ASSY SPINDLE SHORT (SEE FIGURE 5 FOR COMPONENTS) 2721097 S-ASSY SPINDLE LONG (SEE FIGURE 5 FOR COMPONENTS) 64197-003 BLT-TDFM 3/8-16X1.00 2722021.2 CHUTE 112243-02 BLADE 18.00 OFFST LLFT...
-
Page 10: Mounting-36" Ec Sd Deck
MOUNTING-36" EC SD DECK Midsize Decks FIGURE 2... - Page 11 MOUNTING-36" EC SD DECK Midsize Decks FIGURE 2 4115263-02 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 2721481.2 COVER-BELT FIXED DECK 2721470.7 WLDMT-FIXED BRKT RH 2721469.7 WLDMT-FIXED BRKT LH 2721486 SPACER-BELT COVER 64141-11 NUT-WLF 3/8-16 CL 2722059 PIN-GUIDE 64139-21 BLT-WLF 3/8-16 X 3/4 64141-4 NUT-WLF 3/8-16 64123-94...
-
Page 12: 36" Ec Rear Dicharge Deck
36" EC REAR DICHARGE DECK Midsize Decks FIGURE 3... - Page 13 36" EC REAR DISCHARGE DECK Midsize Decks FIGURE 3 4115263-03 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4115087 S-36 DECK RD W/LABS EC 3-40 2720815 BELT-PTO 48 2721323 ASSY-SPINDLE SHORT 3-41 64123-74 BLT-HEX 1/2-13 X 4-1/2 (SEE FIGURE 14 FOR COMPONENTS) 3-42 4115379 SPACER...
- Page 14 CASTER ASSY-FIXED DECKS Midsize Decks FIGURE 4...
-
Page 15: Caster Assy-Fixed Decks
CASTER ASSY-FIXED DECKS Midsize Decks FIGURE 4 4115263-04 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 4115465 ASSY-CASTER 9IN EC (INCLUDES ITEMS 1-3, 7-11 & 20 QTYs LISTED) (NOTE 2 ASSYS REQUIRED PER MACHINE) 64173-04 QUICK PIN 64163-07 1-1/32X1-3/4X1/4 WASH 64163-22 1-1/32X1-3/4X1/2 WASHR 48053-07... - Page 16 SPINDLE ASSEMBLY Midsize Decks FIGURE 5...
-
Page 17: Spindle Assembly
SPINDLE ASSEMBLY Midsize Decks FIGURE 5 2721694-14 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 38348-01 BEARING-SPINDLE SEALED 2 33179-02 SPINDLE-SHORT (USED IN ITEM 8) 33179-01 SPINDLE-LONG (USED IN ITEM 7) 2721096 HOUSING-SPINDLE 6 HOLE 1 64144-38 SNAP-RING 38315 NUT-SPINDLE 2721097 ASSY-SPINDLE LONG (INCLUDES ITEMS 1, 3, 4-6) - Page 18 DECALS Midsize Decks FIGURE 6...
-
Page 19: Decals
DECALS Midsize Decks FIGURE 6 4115263-06 ITEM PART NO. DESCRIPTION ITEM PART NO. DESCRIPTION 2721030 DECAL-RANSOMES 2000685-01 LBL-RED/WHITE STRIPE 55" SIDE DISCHARGE LENGTH 28.4" REAR DISCHARGE LENGTH 28.5" 2000638 LABEL-CON WASHER EEC 1 2000760 LABEL-HANDS/ROCKS EC 2000655 LABEL-READ OPRTRS EEC 1 009034760 LABEL-EEC NOISE 100 2000646 LABEL-CE 95...
