Summary of Contents for Pelican Rev B
- Page 1 Owner’s Manual Whole House Backwashing Sediment Filter System...
- Page 2 Pelican Water Systems shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Adding the Pelican Logo Sticker: ........ -
Page 4: Product Operation And Specifications
Rev B — Whole House Backwashing Sediment Filter System Page 4 Product Operation and Specifications Specification Description 1-6 Bath Tank Max Flow Rate 20 GPM ** Minimum Working Pressure 25 PSI Maximum Working Pressure 100 PSI Maximum Vacuum 5 inch/127 mm Hg Operating Temperatures 36°F - 120°F... -
Page 5: Complete Parts List
Rev B — Whole House Backwashing Sediment Filter System Page 5 Complete Parts List Note: Pelican supplies the parts below to accommodate a variety of water supply lines. Table 1: Parts List Part Description Qty. Part Description Qty. Bypass Valve for Electronic 1"... -
Page 6: Installation Overview
Rev B — Whole House Backwashing Sediment Filter System Page 6 Installation Overview Wall Wall Incoming Water Outgoing Supply Water to House Bypass Valve Electronic Head Discharge Line Sediment Tank Figure 1 Pre-Installation Bypass Valve Installation Bypass Valve Electronic Head... -
Page 7: Installation
Rev B — Whole House Backwashing Sediment Filter System Page 7 Installation Sediment Tank Installation Electronic Head Distributor Tube Figure 3 When Leveling the Sediment Tank: Notice: If the tank is not level, lift the tank straight up 6 inches and tap it on the ground until the tank stands vertical. -
Page 8: Complete The Installation
Rev B — Whole House Backwashing Sediment Filter System Page 8 Complete the Installation 1. Turn on the main water supply. 2. Check for leaks. 3. Plug in the Electronic Head. Programming the Electronic Head Note: Power Source - For safety reasons the outlet must be protected by a Ground Fault Circuit Interrupter (GFCI). -
Page 9: Adding The Pelican Logo Sticker
Rev B — Whole House Backwashing Sediment Filter System Page 9 Adding the Pelican Logo Sticker: 1. Peel back plastic to remove it from the tank. 2. Place sticker in the desired location on the tank. © 2019 Enviro Water Solutions, Inc. -
Page 10: Troubleshooting
Rev B — Whole House Backwashing Sediment Filter System Page 10 Troubleshooting Problem Solution Water leaking at the top of the tank around the head. You may need to turn the head to tighten it. The tank head is pre-installed hand-tight, do not overtighten the head (just turn it snug). -
Page 11: Warranty
These warranties apply only to the original registered owner so long as the owner owns/lives in the home in which the unit was originally installed. Customer must register their system with Pelican within 90 days of purchase* in order to obtain a warranty. Warranty will discontinue after the unit is removed from the location where it was originally installed. -
Page 12: Warranty Registration Form
Rev B — Whole House Backwashing Sediment Filter System Page 12 Warranty Registration Form Send in this Warranty Registration Form to validate your warranty or visit www.PelicanWater.com to complete warranty registration form online. Pelican Warranty Registration Form Date Item(s) were Received:... - Page 13 Rev B — Whole House Backwashing Sediment Filter System Page 13 !IMPORTANT! Do not use where water is microbiologically unsafe or with water of unknown quality without proper disinfection before or after the filter/softener system. © 2019 Enviro Water Solutions, Inc.
