- Page 1 Owner’s Manual Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System...
- Page 2 Pelican Water Systems shall not be liable for technical or editorial errors or omissions contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 3: Table Of Contents
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 3 Table of Contents Table of Contents ............3 Product Operation and Specifications . -
Page 4: Product Operation And Specifications
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 4 Product Operation and Specifications Specification Description Max Flow Rate 10 GPM 15 GPM Minimum Working Pressure 25 PSI Maximum Working Pressure 80 PSI Maximum Vacuum 5 inch/127 mm Hg Operating Temperatures 36°F –... -
Page 5: Complete Parts List
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 5 Complete Parts List Note: Pelican supplies the parts below to accommodate a variety of water supply lines. Table 1: Parts List Part Description Qty. Part Description Qty. - Page 6 Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 6 Part Description Qty. Part Description Qty. Pelican Whole House Pelican Whole House Iron Carbon Filter & Manganese Filter Note: Drawings are not to scale. Additional fittings will be needed to adapt to your plumbing.
-
Page 7: Installation Overview Diagram
Rev T Page 7... -
Page 8: Installation Overview
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Page 8 Filtration System Installation Overview Wall Wall Chemical Injector Spigot Pump Outgoing Drain Line Incoming Water to Barb Water House Supply Chemical Injector Sediment Filter Pump Tubing Solution Tank... - Page 9 Pelican WF4/WF8 Premium Whole House Iron and Manganese Rev T Filtration System Page Bypass Operation SERVICE BYPASS Bypass Allen Wrench Notice: The Bypass Valve on the Electronic Head can be set to Bypass or Service by turning the knobs on the top of the valve.
-
Page 10: Carbon Soak
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Page 10 Filtration System Water Filter - Carbon Soak !IMPORTANT! Your system will not be ready for use for a minimum of 48 hours while the Carbon Soak process takes place. -
Page 11: Carbon Flush
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 11 Water Filter - Carbon Flush !IMPORTANT! Do not perform the Carbon Flush until the Carbon Soak process is complete. Notice: Water will flow out of the outlet side of the Bypass Valve during this process. Be sure you perform this series of steps in a location suitable for water flow. -
Page 12: Installation
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 12 Installation Sediment Filter Assembly Sediment Filter Cover Sediment Filter O-Ring Blue Filter Housing Stand Pipe Figure 5 1. Unscrew the cover from the Blue Filter Housing. -
Page 13: Chemical Injector Pump And Solution Tank Installation
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 13 Chemical Injector Pump Overview Pressure Release Button Flow Direction Arrow Dosage Adjustment Dosage Lock Nut Suction Hose Nut Figure 7 Pressure Release Button Allows you to relieve the air pressure after install and maintenance. -
Page 14: Chemical Injector Pump Installation
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 14 Chemical Injector Pump Installation !IMPORTANT! Install the Chemical Injector Pump onto the water supply after the Sediment Filter and before any other filtration or softening system. -
Page 15: Iron And Manganese Tank Installation
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 15 Iron and Manganese Tank Installation Wall Wall Chemical Injector Spigot Pump Incoming Drain Line Outgoing Water Barb Water to Supply Chemical House Injector Sediment Filter Pump Tubing... - Page 16 Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 16 IMPORTANT! • Ensure the PVC Tubing Backwash Drain Line is not submerged and is free of kinks. • Maximum vertical rise of the backwash line is 6 feet.
-
Page 17: Whole House Water Filter Tank Installation
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 17 Whole House Water Filter Installation 1. Level the Whole House Water Filter. Notice: If the tank is not level, lift the tank straight up 6 inches and tap it on the ground until the tank stands vertical. -
Page 18: Complete The Installation
4. Peel off the protective plastic wrap from the stainless steel tank jackets. 5. Add the Pelican logo sticker in the desired location on the tank. 6. Wax stainless steel tank jacket(s) with wax provided or any other non-abrasive auto wax a minimum of 1-2 times per year or as needed based on the installed environment. -
Page 19: Setting The Electronic Head
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 19 Programming the Electronic Head Note: Power Source - For safety reasons the outlet must be protected by a Ground Fault Circuit Interrupter (GFCI). Your system is pre-set to regenerate every 3 days at 2:00 am, the complete process takes 20 minutes MENU Step 1: Setting the Date &... -
Page 20: Testing Chlorine Levels In Water - Dialing In
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Page 20 Filtration System Testing Chlorine Levels in Water - Dialing In Pressure Release Button Flow Direction Arrow Dosage Adjustment Dosage Lock Nut Suction Hose Nut Figure 13 1. Put the Whole House Water Filter into bypass. (See page 9 for bypass position) 2. -
Page 21: Maintenance
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Page 21 Filtration System Maintenance Sediment Filter It is recommended that the Sediment Filter be replaced every 6-9 months depending on the amount of sediment present in the water supply. If the system has been working properly and the pressure is slowing, it may be time to change the Sediment Filter. -
Page 22: Troubleshooting
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 22 Troubleshooting Problem Solution Water leaking at the top of the tank around the head. You may need to turn the head to tighten it. The tank head is pre-installed hand-tight, do not overtighten the head (just turn it snug). -
Page 23: Warranty
Warranty Pelicans Limited Lifetime Warranty Pelican Water ("Pelican") warrants to the end user ("customer") that its tanks (13" & smaller), in/out heads, bypass's, fittings, NaturSoft media and housings ("Covered Items") will be free from defects in material and workmanship under normal use and service for the life of the system. No warranty is made with respect to... - Page 24 Page 24 Manufacturer’s Performance Guarantee The Pelican PC600 Premium Whole House Water Filter is guaranteed to perform removing Chlorine and Chloramines to an undetectable level for 600,000 gallons or (5) years whichever comes first. The Pelican PC1000 Premium Whole House Water Filter is guaranteed to perform removing Chlorine and Chloramines to an undetectable level for 1,000,000 gallons or (5) years whichever comes first.
-
Page 25: Warranty Registration Form
Rev T Pelican WF4/WF8 Premium Whole House Iron and Manganese Filtration System Page 25 Warranty Registration Form Send in this Warranty Registration Form to validate your warranty or visit www.PelicanWater.com to complete warranty registration form online. Pelican Warranty Registration Form... -
Page 26: Product Certifications
Do not use where water is microbiologically unsafe or with water of unknown quality without proper disinfection before or after the filter/softener system. Product Certifications Pelican NaturSoft-NS3/NS6 – WQA Gold Seal tested and certified under NSF/ ANSI61 for material safety and tested according to NSF/ANSI 42 for structural integrity only Clack V3007-xx Bypass Fittings –...
