Summary of Contents for Barmesa Pumps BSP10ICU
- Page 1 Installation, Operation & Maintenance Manual Self-Priming Frame Mounted Pump BSP10ICU 2" x 2" Universal Drive barmesapumps.com IMPORTANT! - Read all instructions in this manual before operating or servicing a pump.
- Page 2 Also record the Voltage and Current from power source before Readings at Startup: handling any aspect of the pumping IMPORTANT! - Barmesa Pumps is not Model Number: ____________________ system. Lock out power and tag. responsible for losses, injury or death resulting from failure to...
- Page 3 Specifications & Dimensions SUCTION/DISCHARGE: 2" x 2" NPT, female flange. LIQUID TEMPERATURE: 160 °F (71 °C) max. VOLUTE: Cast iron ASTM A-48 class 30. BODY: Cast iron ASTM A-48 class 30. PEDESTAL: Cast iron ASTM A-48 class 30. IMPELLER: Open, trash type, dynamically balanced. Cast iron ASTM A-48 class 30. SHAFT: Stainless steel.
- Page 4 Recommendations, Warnings & Installation Receiving inspection Controls Lubrication Upon receiving the pump, it should Be sure the electrical specification of The seal is the only component that inspected damage the control selected properly match requires lubrication. It is grease filled shortages.
- Page 5 Operation, Service & Repair CAUTION To reassemble, use the required DO NOT OPERATE PUMP WITHOUT PRIMING FIRST. OPERATING number of shims to result in an DRY WILL DAMAGE SEAL. impeller-to-volute clearance of .010" to .020". Starting Shaft seal To start pump, apply power to motor Remove rotating member, spring and MOTOR ENGINE...
- Page 6 Troubleshooting Chart Always disconnect the pump from the electrical power source before handling. If the system fails to operate properly, carefully read instructions and perform maintenance recommendations. Symptom Possible Cause(s) Corrective Action 1. Fill pump body with water. 1. Casing not filled with water 2.
