Summary of Contents for KLING & FREITAG Spectra 212i
- Page 1 EN | VERSION 1.0 | 06/16/21 USER‘S MANUAL K&F SPECTRA 212i Wall Arm...
-
Page 3: Table Of Contents
Installation 5.1 Required Tools 5.2 Adjusting the Tilt Angle 5.2.1 1 x SPECTRA 212i with flying frame (vertical) 5.2.2 1 x SPECTRA 212i with flying frame (horizontal): 5.2.3 2 x SPECTRA 212i with flying frame (horizontal): 5.3 Installing the Load Adapter Install 5.4 Premounting the Flying Frame to the Speaker... -
Page 4: Introduction
User's Manual K&F SPECTRA 212i Wall Arm SPECTRA 212i flying frame 16.06.2021 06/16/21 Introduction SPECTRA 212i Wall Arm Icons Used This icon indicates a risk of injury or death. Not following these instructions may result in seri- WARNING ous health problems including potentially fatal injuries. -
Page 5: Product Description
K&F SPECTRA 212i connector set (line source) or the K&F SPECTRA 212i horizontal cluster set (point source). Also, be sure to use accessories to the SPECTRA 212i speaker system for stationary indoor in- stallations only. The system is not designed for repeated assembly, reconfiguration, disassem- bly, or transport. -
Page 6: Optional Accessories
16.06.2021 06/16/21 Optional accessories Rotation Clamp 450 Technical Specifications 3.0.1 Overview 1 x K&F SPECTRA 212i (vertical installation) or 2 K&F SPEC- Load capacity TRA 212i (horizontal installation) Weight 3.2 kg RAL 9005 (black), standard Colors RAL 9010 (white), standard RAL spot color, on request 3.0.2... -
Page 7: Safety Instructions
Be sure to install, suspend, fasten, and use Kling & Freitag speaker accessories only using the designated fixtures as specified in this document. • Be sure to use accessories to the SPECTRA 212i speaker system for stationary indoor instal- lations only. The system is not designed for repeated assembly, reconfiguration, disassembly, or transport. -
Page 8: Installation
User's Manual K&F SPECTRA 212i Wall Arm SPECTRA 212i flying frame 16.06.2021 06/16/21 Installation When using optional accessories, be sure to follow all instructions in the respective manuals. Required Tools Required Tools hexagon socket wrench IS5 hexagon socket wrench IS10... -
Page 9: Spectra 212I With Flying Frame (Vertical)
User's Manual K&F SPECTRA 212i Wall Arm 5.2.1 1 x SPECTRA 212i with flying frame (vertical) Main directivity in point source mode Main directivity in Load point source mode WHITE MARK (– adapter Load adapter Speaker tilt angle 10°) RED MARK (+10°) -
Page 10: Spectra 212I With Flying Frame (Horizontal)
User's Manual K&F SPECTRA 212i Wall Arm SPECTRA 212i flying frame 16.06.2021 06/16/21 5.2.2 1 x SPECTRA 212i with flying frame (horizontal): Alignment of the load adapt- Holes for Main directivity (tilt) Load Adapter -54.6 1/2 Grid -52.3 1/1 Grid -49.9... -
Page 11: Spectra 212I With Flying Frame (Horizontal)
User's Manual K&F SPECTRA 212i Wall Arm 5.2.3 2 x SPECTRA 212i with flying frame (horizontal): Alignment of the load adapt- Holes for speaker tilt Load Adapter -45.3 1/2 Grid -43.3 1/1 Grid -41.2 1/2 Grid -39.0 1/1 Grid -36.9 1/2 Grid -34.7... -
Page 12: Installing The Load Adapter Install
User's Manual K&F SPECTRA 212i Wall Arm SPECTRA 212i flying frame 16.06.2021 06/16/21 Installing the Load Adapter Install 1. Align the load adapter install with the holes in the flying frame as determined from the above table. 2. Check the load adapter for cor- rect orientation. -
Page 13: Spectra 212I, Horizontal Suspension
User's Manual K&F SPECTRA 212i Wall Arm 5.4.2 SPECTRA 212i, horizontal suspension Danger from loosening connections WARNING The fixing screws are self-locking and must be used no more than five times. Using them more often may result in screws loosening in operation. If in doubt, use new screws. Never use other types of screws. -
Page 14: Maintenance
User's Manual K&F SPECTRA 212i Wall Arm SPECTRA 212i flying frame 16.06.2021 06/16/21 Maintenance • Perform a visual inspection before each installation. • Visually inspect the entire setup every six months. • When performing those checks, particularly look for deformations, cracks, dents, damage to threads, and corrosion. -
Page 15: Declaration Of Conformity
User's Manual K&F SPECTRA 212i Wall Arm Declaration of Conformity © KLING & FREITAG GMBH Version 1.0 Page 15 of 15... - Page 16 THANK CHOOSING K&F. KLING & FREITAG GmbH Junkersstrasse 14 · D-30179 Hannover Phone +49 (0)511 969970 www.kling-freitag.de · info@kling-freitag.de...
