Volpi Olytech Dualcomb 255SP Operation And Maintenance Manual page 30

Codes 355SP-L-XL Ref. fig. G.2
Pos. Code
1 255K1 RIGHT AND LEFT HEAD CRANKCASE KIT FOR DUALCOMB
2 CP0013 POLE INSERT D32 H64
3 205/212 HEAD ANTI-ROTATION INSERT 205-305
4 205/213D RIGHT SIDE DOOR (HEAD) 205-305
5 205/213S LEFT SIDE DOOR (HEAD) 205-305
6 305/204C 7-TINES COMB WITH BEARINGS 205
7 405/211C COMPLETE HEAD CONNECTING ROD 205-305
8 205K2 KIT PIN-RODS-BEARINGS-SEEGER FOR 205-305
CM0026 COMPLETE MOTOR GROUP 12V WITH FRAME AND GEARS
9
OLYTECH
10 405/315 MOTOR WIRING 255-355-455-555-655
11 405/612 POWER CABLE FOR 255-355-455-755
12 705/620 COMPLETE FEMALE CONNECTOR
13 205L/400 TELESCOPIC POLE WITH HANDLE AND CABLE 205L-305L
14 205XL/400 TELESCOPIC POLE WITH HANDLE AND CABLE 205XL-305XL
405/509 COMPLETE BLOCKING GROUP FOR TELESCOPIC POLE 405-
15
505-605
16 702/223 ON-OFF SWITCH IP65
405/403 WIRE WITH MALE CONNECTOR FOR POLE 255-355-455-555-
17
655 LTOT=0,38 M
18 405/620 COMPLETE MALE CONNECTOR
handle shells group with U-bolt
19 405/410C
spiral cable 2x2.5 mmq 255-355-455 SERIE " L"
20 405L/402
spiral cable 2x2.5 mmq 255-355-455 SERIE "XL"
21 405XL/402
Wired thermal protector for el. Motor 12V 405
22 405/220TP
Oxidized extension pole COLOR black D.37x1200
23 405L/508
Oxidized pole in aluminium color grey D.32x1300
24 905L/401
Oxidized extension pole color black D.37x1500
25 405XL/508
Oxidized pole in aluminium color grey D.32x1600
26 705/401
saddle 32-37 for GIULIVO PLUS short SP
27 705/412
Oxidized pole in aluminium Ø32 for handle
28 TALL01
Complete cable pole without extension 12V 2X2,5mm
29 WCAB07
Fixed pole with handle and cable 12V 255 SP 355SP
30 ASTSP02
KIT NUTS AND BOLTS OLYTECH DUALCOMB
- 205/022
COMPANY WITH QUALITY SYSTEM
MANAGEMENT CERTIFIED BY ICIM
Part Description
Tel. +39 0376 76009 Fax +39 0376 76408 www.volpioriginale.it
= ISO 9001 =
Davide e Luigi Volpi S.p.A.
Via San Rocco, 10 – 46040 Casalromano (MN) – Italia
commerciale@volpioriginale.it - export@volpioriginale.it
Part per Pcs per
Machine Package
1 1
1 1
1 1
1 1
1 1
2 2
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
1 1
Notes
355L only
355XL only
355L only
355XL only
355L only
355L only
355XL only
355XL only
355SP only
355SP only
355SP only
355SP only
30
