Premier designs WndGarden 26825 Assembly Instructions

26" Modern Fire Truck Spinner
sku #26825 assembly
instructions
Completed Internal Strut Assembly.
Make sure all parts connect as shown.
Star Lock Hub
Front Strut Assembly
Body Sleeve
Body Sleeve Rear Strut Assembly
will have to be Star Lock Hub
(Internal Body
connected to
Struts)
Internal Body Struts
Velcro
Seam
Push Star Lock Hub rmly
onto Plastic Tip of Support Pole
NOTE: To make insertion process
Plastic Tip of Support Pole
easier, place bottom of Support Pole
on a hard, at surface and push
down on Star Lock Hub.
Support Pole
Step 1
Remove your Modern Fire Truck Spinner from the package. The Strut Assembly is shipped in two sections. Open the Velcro seam along the
bottom of the Fire Truck. Connect the Rod of the Front Strut Assembly to the Star Lock Hub of the Internal Rear Strut Assembly. (Diagram
A)
Step 2
Slide the narrow, plastic tipped end of the Support Pole into Star Lock Hub. Push down on the hub until the Support Pole locks into place
and cannot be removed. Close Velcro Seam. (Diagram B)
