WindGarden
b y
p r e m i e r
d e s i g n s
Plane Fuselage x 1
Wing Struts x 2
Support Pole x 1
Channel Holes
Main Fuselage
Hub
Bottom of Wing
Fuselage
Gee Bee Spinner
Long Wing Strut
Short Wing Strut
openings in seams of the wing tip
for inserting wing struts
Aluminum
Channel
Wing Strut
Spinner Propeller x 1
Landing Gear Wheel Axle x 1
Stabilizer Cross Strut x 1
Ground Stake x 1
Wing
Step 1
Insert the two Wing Struts through the two
openings at the wing tip of one of the
wings. Guide them through the internal
sleeves sewn inside of the wings. The
longer of the two struts is inserted through
pocket closer to the leading edge of the
wing. (diagrams A & B)
Step 2
Pass the struts through the Channel Holes
in the fuselage, found underneath the
wings and through the Aluminum Channel
inside the fuselage. Guide the struts
through the internal sleeves of the other
wing to the end of the wing tip. This wing
tip should be sewn closed, so the struts can
not pass through. (diagram C)
assembly
instructions
Wing Opening
for struts
Wing Strut
Advertisement
Related Manuals for Premier designs Wind Garden Gee Bee Spinner
Summary of Contents for Premier designs Wind Garden Gee Bee Spinner
- Page 1 WindGarden Gee Bee Spinner assembly p r e m i e r d e s i g n s instructions Spinner Propeller x 1 Plane Fuselage x 1 Landing Gear Wheel Axle x 1 Wing Struts x 2 Stabilizer Cross Strut x 1 Support Pole x 1 Ground Stake x 1 Wing Opening...
- Page 2 Step 3 nsert the Landing Gear Wheel Axle into the two black fittings located between the two landing gear panels located underneath the wings. (diagram D) Step 4 Insert the Stabilizer Strut into the opening of the Stabilizer Sleeve located underneath the stabilizer.
