Plane Fuselage x 1
EL313
Wing Struts x 2
Support Pole x 1
Channel Holes
Main Fuselage
Hub
Bottom of Wing
Fuselage
Spitfire Airplane Spinner
WJ
K
Bottom of Wing
Aluminum
Wing Strut
Wing Strut
Channel
Wing Strut
Spinner Propeller x 1
Stabilizer Cross Strut x 1
Ground Stake x 1
Wing Opening
Wing
Step 1
Insert the two Wing Struts through the two
openings at the wing tip of one of the
wings. Guide them through the inside of
the wings.
(diagrams A & B)
Step 2
Pass the struts through the Channel Holes
in the fuselage, found underneath the
wings and through the Aluminum Channel
inside the fuselage. Guide the struts
through the inside of the wing to the other
wing to the end of the wing tip. This wing
tip should be sewn closed, so the struts can
not pass through. You may have to shift the
Fuselage Channels Holes slightly to guide
them through. (diagram C)
assembly
instructions
for struts
Wing Strut
