Recommended spare parts (Mechanical version)
No. Description
1 Casing top half
2 Casing bottom half
3 Impeller
4 Shaft
5 Neck ring (Wear ring)
6 Impeller key
7 Shaft sleeve
8 O-ring
9 Cowl sleeve
10 Sleeve nut
11 Stuffing box bush
12 Mechanical Seal
13 Mechanical Seal Gland Plate
14 Stud for gland
15 Bearing end cover (Drive End)
16 Bearing (Drive End)
17 Bearing housing (Drive End)
18 Thrust collar
19 Bearing end cover (Non Drive End)
20 Stud for bearing end cover
21 Bush Bearing (Non Drive End)
22 Lock washer
23 Lock nut
24 Bearing housing (Non Drive End)
25 Hex plug
26 Air cock
27 Hex screw for jacking
28 Studs for split flange
29 Coupling key
30 Gasket
31 Water thrower
32 Steady pin
33 Stud coupling
34 Sealing connection (Flushing Pipe)
35 Hex screw for bearing housing
36 4 way valve
37 Pump Stool
38 Motor Stool
Installation and operating instructions Wilo – SCV pumps
Quantity Recommended Spare
Parts
1
1
1
1
2 ‡
1
2
2
2
4
2
2 ‡
‡
2
2
1
1 ‡
1
1
1
1
1 ‡
1 ‡
1 ‡
1
–
1 ‡
2
–
1
1 ‡
1
–
4
2 ‡
8
2 ‡
1
1
28
