Recommended spare parts (Gland pack version)
No. Description
1 Casing top half
2 Casing bottom half
3 Impeller
4 Shaft
5 Neck ring (Wear ring)
6 Impeller key
7 Shaft sleeve
8 O-ring
9 Cowl sleeve
10 Sleeve nut
11 Stuffing box bush
12 Gland packing
13 Logging ring
14 Gland
15 Stud for gland
16 Bearing end cover (Drive End)
17 Bearing (Drive End)
18 Bearing housing (Drive End)
19 Thrust collar
20 Bearing end cover (Non Drive End)
21 Stud for bearing end cover
22 Bush Bearing (Non Drive End)
23 Lock washer
24 Lock nut
25 Bearing housing (Non Drive End)
26 Hex plug
27 Air cock
28 Hex screw for jacking
29 Studs for split flange
30 Coupling key
31 Gasket
32 Water thrower
33 Steady pin
34 Stud coupling
35 Sealing connection (Flushing Pipe)
36 Hex screw for bearing housing
37 4 way valve
38 Pump Stool
39 Motor Stool
Installation and operating instructions Wilo – SCV pumps
Quantity Recommended Spare
Parts
1
1
1
1
2 ‡
1
2
2
2
4
2
Set ‡
‡
1
1
2
1
1 ‡
1
1
1
1
1 ‡
1 ‡
1 ‡
1
–
1 ‡
2
–
1
1 ‡
1
–
4
2 ‡
8
2 ‡
1
1
