1 ___*___ TruXedo Lo Pro Replacement Cover
2 ___*___ Black Front Header
3 ___*___ Header Seal Front
4 1117540 Front Header 08 End Plugs (Set of Two)
5 1704707 Header Guide
6 ___*___ Retainer Strap
7 1700428 Washer Flat 5/16"
8 1704606 Cap Screw, 5/16-18 x 5/8"
9 1117591 Header Guide Retainer
10 1704194 Weld Nut 5/16-18 ZP
TruXedo Inc. • 2209 Kellen Gross Drive Yankton, SD 57078 • 877-878-9336 • truxedo.com ©TruXedo Inc., 2021
TRUXEDO LO PRO REPLACEMENT PARTS
11 ___*___ Extruded Retainer Loop
12 ___*___ Header Seal Rear
13 1705052 End Plug, 1" OD
14 ___*___ Black Bow
15 1702992 Spring Plunger, 5/8" x 2.15"
16 1703260 Tension Control Bracket
17 1115354 Header Insert Retainer Clip
18 ___*___ Hook and Loop Fasteners
19 1703332 Hitch Pin, 1/16" x 1 5/16"
20 1705392 Aluminum Clamp Assy
21 ___*___ Side Rail, Passenger's Side
22 ___*___ Side Rail, Driver's Side
23 1114773 Flat Spring, 5/8" x 3 7/8"
24 1704213 Latch Assembled
25 1702926 Cap Screw, 5/16" x 7/8"
26 1704187 Header Stop
27 1118094 Side Rail End Plugs w/Seal (Set of Two)
28 1705629 Square Head Screw (#1 Drive)
29 1117467 Rear Header 08 End Plugs (Set of Two)
30 ___*___ Black Rear Header
* Please specify length or make and model of vehicle.
Part# 1118085 Rev. C 03.10.2021
