Parking Brake Operation

Apply the Parking Brake:
1. To lock the parking brake, release the ground speed
pedals (A, Figure 5).
2. Push down on the brake pedal (B).
3. Pull the parking brake knob (C) out.
4. Release the brake pedal.
5
Release the Parking Brake:
1. Push down on the brake pedal (B).
2. Push in the parking brake knob (C).

Engine

Check and Add Engine Oil
®
Use Briggs & Stratton Warranty Certified oils for best
performance. Other high-quality detergent oils are acceptable
if classified for service SF, SG, SH, SJ or higher. Do not use
special additives.
Outdoor temperatures determine the proper oil viscosity for
the engine. Use the chart to select the best viscosity for the
outdoor temperature range expected.
A SAE 30 - Below 40 °F (4 °C) the use of SAE 30 will result in hard
starting.
B 10W-30 - Above 80 °F (27 °C) the use of 10W-30 can cause increased
oil consumption. Check oil level more frequently.
C 5W-30
D Synthetic 5W-30
E Vanguard
®
Synthetic 15W-50
*Below 40°F (4°C) the use of SAE 30 will result in hard starting.
**Above 80°F (27°C) the use of 10W-30 can cause increased oil consumption.
1. Put the unit on a level surface as shown in Figure 6.
6
2. Stop the engine and remove the key. Make sure that the
oil fill area is clean.
3. Remove the dipstick (A, Figure 7). Remove the remaining
oil from the dipstick.
4. Install and tighten the dipstick.
5. Remove the dipstick again, and check the oil level.
6. Make sure that the oil level is at the top of the FULL mark
(B) on the dipstick.
7. If the oil level is FULL, install and tighten the dipstick.
8. If the oil level is LOW, add oil into the oil fill tube (C).
Note: DO NOT add oil at the quick oil drain (if equipped).
9. Wait one minute, and check the oil level again.
10. Install and tighten the dipstick.
