ZSE30A
Series

Specifications

Model
Rated pressure range
Regulating pressure range
Proof pressure
Setting/display resolution
Applicable fluid
Power supply voltage
Current consumption
Switch output
Maximum load current
Maximum applied voltage
Residual voltage
Response time
Short circuit protection
Repeatability
Hysteresis mode
Hystere-
sis
Window comparator mode
Note 2) Output voltage
Voltage
Linearity
output
Output impedance
Analogue
Output current
output
Note 3)
Linearity
Current
output
Load impedance
Display
Display accuracy
Indicator light
Enclosure
Operating temperature range
Operating humidity range
Environ-
ment Withstand voltage
resistance
Insulation resistance
Vibration resistance
Impact resistance
Temperature characteristics
Lead wire
Standards
Note 1) If applied pressure fluctuates near the set value, set the hysteresis above the fluctuation range to prevent chattering.
Note 2) When analogue the voltage output is selected, a simultaneous selection of switch output and current output is not available.
Note 3) When analogue the current output is selected, a simultaneous selection of switch output and voltage output is not available.
Piping Specifications
Model
Port size
One-touch fitting, Straight type
One-touch fitting, Elbow type
Sensor pressure receiving area
Wetted
parts
Piping port
material
Including lead wire with connector (3 cores, 2 m)
Weight Including lead wire with connector (4 cores, 2 m)
Excluding lead wire with connector
Optional Part No.
When optional parts are required separately, use the following part numbers to place an order.
Part no. Option
ZS-38-A1
Bracket A
ZS-38-A2
Bracket B
ZS-27-C
Panel mount adapter
ZS-27-D
Panel mount adapter + front protection cover
ZS-27-01
Front protection cover
ZS-38-3L
Lead wire with connector
ZS-38-4L
Lead wire with connector
ZS-38-3G
Lead wire with connector (with connector cover)
ZS-38-4G
Lead wire with connector (with connector cover)
2
( F ) /ISE30A
ZSE30A
(Vacuum pressure)
0.0 to –101.0 kPa
10.0 to –105.0 kPa
500 kPa
0.1 kPa
12 to 24 VDC ±10%, Ripple (p-p) 10% or less (with power supply polarity protection)
NPN or PNP open collector 1 output, NPN or PNP open collector 2 outputs (selectable)
2.5 ms or less (with anti-chattering function: 20, 100, 500, 1000, 2000 ms)
1 to 5V ±2.5% F.S. or less (with rated pressure range)
4 to 20 mA ±2.5% F.S. or less (with rated pressure range)
Maximum load impedance: 300 Ω with power supply voltage of 12 V; 600 Ω with power supply voltage of 24 V
Minimum load impedance: 50 Ω
Lights up when switch output is ON. OUT1: Green, OUT2: Red
Operating: 0 to 50°C, Stored: –10 to 60°C (no freezing or condensation)
50 MΩ or more between live parts and enclosure (at 500 VDC Mega)
10 to 150 Hz, 1.5 mm amplitude (or 20 m/s
100 m/s
Oilproof heavy-duty vinyl cable, 3 cores
01 N01
R1/8 NPT1/8
M5 x 0.8 M5 x 0.8
— —
— —
C3602 (electroless nickel plated)
O-ring: HNBR
81 g
85 g
43 g
Note
Mounting screw (with 2 pcs. of M3 x 5L)
Mounting screw (with 2 pcs. of M3 x 5L)
Mounting screw (with 2 pcs. of M3 x 8L)
Mounting screw (with 2 pcs. of M3 x 8L)
3 cores, for 1 output, 2 m
4 cores, for 2 outputs, 2 m
3 cores, for 1 output, 2 m
4 cores, for 2 outputs, 2 m
ZSE30AF
(Compound pressure)
–100.0 to 100.0 kPa
–105.0 to 105.0 kPa
500 kPa
0.1 kPa
Air, non-corrosive gas, non-flammable gas
40 mA or less
80 mA
28 V (with NPN output)
1 V or less (with load current of 80 mA)
With short circuit protection
±0.2% F.S. ±1 digit
Variable (0 or above)
±1% F.S. or less
Approx. 1 kΩ
±1% F.S. or less
4-digit, 7-segment, 2-colour LCD (Red and Green)
±2% F.S. ±1 digit (ambient temperature of 25 ±3°C)
IP40
Operating/Stored: 35 to 85% RH (no condensation)
1000 VAC for 1 minute between live parts and enclosure
2
acceleration), in X, Y, Z directions, for 2 hours each (Non-energized)
2
in X, Y, Z directions, 3 times each (non-energised)
±2% F.S. (based on 25°C)
ø3.5, 2 m
4 cores Conductor area: 0.15 mm
CE Marking, UL/CSA, RoHS compliance
C4H C6H N7H
— —
ø4 mm
ø6 mm ø1/4 inch
ø5/32 inch
— —
Sensor pressure receiving area: Silicon
PBT, POM, Stainless steel 304, C3604 (electroless nickel plated)
70 g 71 g 73 g
74 g 75 g 77 g
32 g 33 g 35 g
Part no.
ZS-38-5L
Lead wire with a connector for copying
ZS-38-U
Lead wire unit with a connector for copying
ZS-38-C4H
One-touch fittings ø4 mm straight
ZS-38-C6H
One-touch fittings ø6 mm straight
ZS-38-N7H
One-touch fittings ø1/4 inch straight
ZS-38-C4L
One-touch fittings ø4 mm elbow
ZS-38-C6L
One-touch fittings ø6 mm elbow
ZS-38-N7L
One-touch fittings ø1/4 inch elbow
ZS-38-H
Operating manual CD-ROM
ISE30A
(Positive pressure)
–0.100 to 1.000 MPa
–0.105 to 1.050 MPa
1.5 MPa
0.001 MPa
Note 1)
0.6 to 5 V ±2.5% F.S. or less (with rated pressure range)
2.4 to 20 mA ±2.5% F.S. or less (with rated pressure range)
2
(AWG26), Insulator O.D.: 1.0 mm
C4L C6L
— — —
— —
ø4 mm
— ø6 mm
ø5/32 inch
O-ring: NBR
75 g 73 g
79 g 77 g
37 g 35 g
Option
3 cores, copy function, 1 m
Copy function (up to 10 slaves)
O-ring, one-touch clip included
O-ring, one-touch clip included
O-ring, one-touch clip included
O-ring, one-touch clip included
O-ring, one-touch clip included
O-ring, one-touch clip included
N7L
—
—
ø1/4 inch
75 g
79 g
37 g
Note
