WARNING!
The shock absorber is provided with a
separate type reservoir filled with high pressure
nitrogen gas. To prevent danger of explosion,
study and make certain that you fully
understand the following information before
handling the shock absorber. The manufacturer
cannot be held responsible for damage to
property or personal injury that may result from
improper handling.
1. Never tamper with or attempt to
disassemble the cylinder or the reservoir.
2. Never expose the shock absorber to an
open flame or other excessive heat. The
shock absorber may othervise explode due
to too high pressure.
3. Be careful not to damage any part of the
gas reservoir. A damaged gas reservoir will
impair the damping performance or cause
malfunction.
4. Take care not to scratch the contact
surface of the piston rod of the cylinder; oil
could othervise leak out.
5. Never attempt to remove the plug at the
bottom of the nitrogen gas reservoir. Any
attempt to remove the plug implies serious
danger.
6. When scrapping the shock absorber,
follow the instructions for disposal.
Traction, handling,
comfort and safety
Öhlins Racing AB, Box 722, S-194 27 Upplands Väsby, Sweden.
Phone +46 8 590 025 00, fax +46 8 590 025 80.
E-mail: info@ohlins.se
Web: www.ohlins.com
Notes
Mounting instructions
HO 404 - RC 45
Kit contents
Shock absorber Type 46 HRC
HO 404
Sticker
00192-01
Hook spanner
00710-02
Mounting rubber
00230-03
Tie-rap
00231-01
Hose clamp
00643-02
Owners manual
Set-up data
Total lenght
295,5 mm
Stroke
55 mm
Preload spring
8 mm
Rebound adj.
10
Compression adj.
8
1
2
1
2
2
2
1
