3 Components
a a
a
a Faston connectors
9 Install the cover of the compressor wire terminals.
a
a Compressor wire terminals cover
10 Add refrigerant to the refrigerant circuit, see
procedures" on page 136.
11 Install the compressor
procedures" on page 84.
Is the problem solved?
Yes
No
To remove the compressor insulation
Prerequisite: Stop the unit operation (via the user interface, central
controller, operation switch, ...).
Prerequisite: Turn OFF the respective circuit breaker.
Prerequisite: Remove the required plate work, see
work" on page 118.
1 Detach all the strips (a).
Service manual
86
https://daikin-p.ru/catalog/vrv-daikn/naruzhnye-vrv-bloki-daikin
"4.2.2 Repair
insulation, see "3.2.2 Repair
Action
No further actions required.
Return to the troubleshooting of
the specific error and continue
with the next procedure.
"3.13 Plate
a
a Strip
2 Detach the strip (b) of the top jacket (c).
3 Remove the top jacket (c).
4 Remove the body jacket (d) from the compressor (e).
b Strip
c Top jacket
d Body jacket
e Compressor
To install the compressor insulation
b Strip
c Top jacket
d Body jacket
e Compressor
1 Install the body jacket (d) on the compressor (e).
2 Install the top jacket (c).
3 attach the strip (b) to the top jacket (c).
a
a
a
c
b
e
d
c
b
e
d
RYYQ+RYMQ+RXYQ8~20U7Y1B
VRV IV+ Heat Pump
ESIE18-14 – 2019.07
