6 Technical data
RYMQ-U / Defrost operation
k
R5T R6T
Y2E
a
b
f
c
Indoor units conditions:
• Indoor unit 1: Operation ON, Thermo ON, Fan ON, Expansion valve: normal control
• Indoor unit 2: Operation OFF, Fan OFF, Expansion valve: closed (0 pulse)
• Indoor unit 3: Operation ON, Thermo OFF, Fan ON, Expansion valve: closed (0 pulse)
