This chapter details the specifications of the PCI quad RS422/485 card and
explains how to configure the RS485 Multiplex jumpers present on both cards.
These half-sized cards will work happily in any PCI 2.0 or greater compliant PC
compatible.
½
Four independent 9 pin D RS422/485 Serial ports.
½
Reliable communications up to 4000 feet, 1.2 Kilometres.
½
16950 FIFO provides 128-byte input and 128-byte output buffer on each
port.
½
Maximum baud rate of 912600 Baud (1 Megabaud).
½
Word length of 5, 6, 7 or 8 bits.
½
Even, Odd, None, Mark or Space parity options.
½
1 start bit always sent.
½
1, (1.5 for 5-bit data word length), or 2 stop bits.
½
TXD, RXD, RTS, and CTS signals.
½
RS485 TXD/RXD multiplex selectable by jumpers: - either FULL
DUPLEX or HALF-DUPLEX.
½
Fully double buffered for reliable asynchronous operation.
½
High-speed integrated circuitry ensures operation with fast PC's e.g. 800
MHz Pentium II WITHOUT extra wait states.
½
Autogating low level RS485 half duplex (2 wire) control
Clock Input:
Drivers:
High Level Voltage:
Low Level Voltage:
High Level Current:
Low Level Current:
Receivers:
Difftial I/P threshold:
Hysteresis:
Input Impedance:
60.00mHz
SN75174
3.7V typical at 33mA source
1.1V typical at 33mA source
-60mA max.
60mA max.
SN75175.
200mV max.
50mVolt typical.
>12K Ohm without terminators.
•
