U.S. Products COBRA Information & Operating Instructions

120v
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
COBRA
®
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE THE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THESE INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, avoid extremes in temperatures, and store
in a heated location. Use the machine indoors only.
3. Use approved chemicals only. NO SOLVENTS.
4. All extension cords must be at least size #12 (12/3) and no longer than 50 ft.
5. Never leave the machine plugged in when you are not attending it.
6. Never use water above 130º F/54º C in the solution tank.
1
5-2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COBRA and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Products COBRA

Summary of Contents for U.S. Products COBRA

  • Page 1 COBRA ® EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE THE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THESE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your COBRA for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts.
  • Page 4 OPERATION: Inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Fill the solution tank with water. Using warm water may be a benefit in cleaning effectiveness, but do not use hot water (above 130 F / 54 C) in the tank. °...

  • Page 5: Parts List

    COBRA (NO HEAT) 120V PARTS LIST ITEM # PART # DESCRIPTION ITEM# PART# DESCRIPTION Hose Clamp FP231A Drain Gate, complete 108A Hose Barb/Elbow Screw, 8-32" X 5/8", S/S FP165C Hose, Rubber, 3/8 X 13" Latch Hose, Rubber, 3/8 X 22"...

  • Page 7: Specifications

    SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Two, 2-stage 5.7” vacuums Vacuum: Ball float VAC Shutoff: Demand pump, 100 psi Pump: 150” Waterlift: Stainless steel, single bend, twin tip Wand: 69 lbs. Weight: 26.5H x 18W x 28.75L (inches) Dimensions: TROUBLE SHOOTING: IF THIS OCCURS CHECK THIS NO SPRAY...
  • Page 8 COBRA EXTRACTOR 120V NOTES: 208-772-0573 800-257-7982 FAX: 208-772-0577 VISIT US AT: http://www.usproducts.com...
