U.S. Products XLT-60 Information & Operating Instructions

Extractor 240v
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. NEVER USE SOLVENT IN THE MACHINE. Use neutral pH, water-based products only!
2. Never use water with a temperature above 54 °C/130 °F in the solution tank.
3. The recovery bucket should be emptied each time the holding tank is filled.
4. Always make sure the float travels freely up and down the rod after emptying the recovery bucket.
5. Always use a drop cloth under the machine during operation.
6. Vacuum any unused solution out of the solution tank and empty the recovery bucket after each job.
7. Keep machine from rain and snow, extremes in temperatures, and store in a heated location.
Use the machine indoors. Do not use outdoors.
8. Do not run the pump dry.
9. Never operate a machine that is leaking or in need of a repair.
10. Always use a defoamer. The vacuum shut-off will not activate properly if foam is in the recovery
bucket. Water damage to the vacuum motor or other components will void the warranty.
If you have any questions before you operate the machine, call your supplier for instruction.
XLT-60
EXTRACTOR
240V
ALL SECTIONS OF THE INSTRUCTIONS
INFORMATION
&
OPERATING
INSTRUCTIONS
1-25-2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XLT-60 and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Products XLT-60

Summary of Contents for U.S. Products XLT-60

  • Page 1 XLT-60 EXTRACTOR 240V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. NEVER USE SOLVENT IN THE MACHINE. Use neutral pH, water-based products only! 2.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops, and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your XLT-60 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts.
  • Page 4 STEP #1 Make sure the recovery bucket under the dome is in the correct position. If the dome will not seat properly, lift off the dome, and see if the bucket needs to rotate 180 degrees. The bucket must set level; the float rod should be next to the switches.
  • Page 5 XLT-60 06.29.2008...
  • Page 6 XLT-60 240V PARTS LIST ITEM# P A R T # D E S C R I P T I O N ITEM# PART# D E S C R I P T I O N FP368 Vacuum Dome, no Gasket Nut, Nylon...

  • Page 7: Specifications

    WIRING: XLT-60 SPECIFICATIONS: Vacuum: 80” water lift - 97 CFM Heat Exchanger: Stainless steel coil, instant heat transfer Pump: 7 bar (100 psi) diaphram, “on-demand” Circuit Board: Solid-state technology controls heating operation Electrical System: 7.6 M 12/3 cord 240V 50/60 cycle Weight: 19.5 Kg...
  • Page 8 XLT-60 EXTRACTOR 240V NOTES: 425-322-0133 / 800-257-7982 / FAX: 425-322-0136 11015 - 47th Ave. W. / Mukilteo, WA 98275 VISIT US AT: http://www.usproducts.com...
