U.S. Products COBRA PLUS-300 Information & Operating Instructions

120v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CP-300
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THE INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a heated
location. Use the machine indoors. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
02/12/2003
06.04.2007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COBRA PLUS-300 and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Products COBRA PLUS-300

Summary of Contents for U.S. Products COBRA PLUS-300

  • Page 1 CP-300 EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage. 2.
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.
  • Page 3 INSPECTION: Carefully unpack and inspect your COBRA PLUS-300 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts.
  • Page 4 ADJUST Record the serial number and model of your new extractor here: (and be sure to mail your warranty card) Serial Number: __________________ Model: COBRA PLUS-300 Purchase Date:_____________ Write the name and phone number of your distributor: _____________________________________ _____________________________________ OPERATION Inspect the machine, hoses, and cleaning tools for cleanliness and completeness.
  • Page 5 increase pump speed, and prime the air out of the pump. When the water is clear (no air in it) turn the pump off, and remove the priming hose. NOTE: if priming is difficult, place the open end of the priming hose into the Vacuum inlet hose barb, and turn the vacuum on.
  • Page 7 COBRA PLUS-300 EXTRACTOR PART LIST 120V ITEM PART No DESCRIPTION ITEM PART No. DESCRIPTION Chain, lid, 8” FP336 Snap track, 4” PCB mounting FP446 Lid, holding tank 1377 Hose, hydraulic, 27-3/4” 207A Filter, pump inlet Hose clamp 1088 Glide, teflon 1137 Adapter, ABS, 1-1/2”...
  • Page 8 CP-300 EXTRACTOR 120V SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Vacuum: 7.2”, 3-stage soft start vac VAC Shutoff: Electronic Pump: Positive displacement, fully adjustable, 0-300 psi Waterlift: 140” Heat: Fully adjustable 145ºF to 212º F Heater: 2000 Watts Wand: Stainless steel, double bend, twin tip Weight: 105 lbs.
