U.S. Products COBRA PLUS-310 Information & Operating Instructions

120v
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
CP-310
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THE INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. Use the machine indoors. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
06.04.2007

Advertisement

loading
Need help?

Need help?

Do you have a question about the COBRA PLUS-310 and is the answer not in the manual?

Questions and answers

Related Manuals for U.S. Products COBRA PLUS-310

Summary of Contents for U.S. Products COBRA PLUS-310

  • Page 1 CP-310 EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage. 2.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Maintenance

    INSPECTION: Carefully unpack and inspect your COBRA PLUS-310 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts.
  • Page 4 ON/OFF SWITCH Record the serial number and model of your new extractor here: (and be sure to mail your warranty card) Serial Number: __________________ Model: COBRA PLUS-310 Purchase Date:_____________ Write the name and phone number of your distributor: _____________________________________ _____________________________________ OPERATION Inspect the machine, hoses, and cleaning tools for cleanliness and completeness.
  • Page 5 block the open area in the hose barb. This will allow the pump and the vacuum to work together to get the water moving. Priming may take 20-60 seconds, and the solution tank should be full. Once the pump is primed, turn the pump and the vacuum OFF. Remove the priming hose.
  • Page 7 COBRA PLUS-310 EXTRACTOR PART LIST 120V ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION Chain, lid, 8” 2025 Heat sink plate FP446 Lid, solution tank ------ See miscellaneous HKCR1 Holding tank, white Louver, 3”, includes screws 1088 Glide, teflon 1377 Hose, hydraulic, 27-3/4"...

  • Page 8: Specifications

    CP-310 EXTRACTOR 120V SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Vacuum: 7.2” 3-stage VAC Shutoff: Ball float Pump: Positive displacement, selectable pressure setting Waterlift: 140” Heat: Instant to 212º F Heater: 2000 Watts Wand: Stainless steel, double bend, twin tip Weight: 112 lbs. Dimensions: 38”...
