U.S. Products KING COBRA-1200 PRO 240V Information & Operating Instructions

Dual surface extractor
Hide thumbs

Advertisement

Quick Links

Download this manual
KC-1200 PRO 240V
DUAL SURFACE EXTRACTOR
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. DANGER: High spraying pressure may cause severe injury. Always wear safety
glasses. Keep hands away from spray. Never direct the spray towards people or pets.
2. Never allow the spray to remain fixed in one spot.
3. Before each use, remove the spray tool from the hose, and check to make sure the spray
nozzle is securely tightened to the spray tool. A loose nozzle could fly off during use.
4. If a leak occurs at the hose, IMMEDIATELY turn the machine off. Replace hose before
restarting.
5. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
6. Keep the machine from rain and snow, extremes in temperatures, and store it in a heated
location. Use the machine indoors. Do not use outdoors.
ALL SECTIONS OF THESE INSTRUCTIONS
INFORMATION
&
OPERATING
INSTRUCTIONS
November 21, 2006

Advertisement

loading
Need help?

Need help?

Do you have a question about the KING COBRA-1200 PRO 240V and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U.S. Products KING COBRA-1200 PRO 240V

Summary of Contents for U.S. Products KING COBRA-1200 PRO 240V

  • Page 1 KC-1200 PRO 240V DUAL SURFACE EXTRACTOR INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THESE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. DANGER: High spraying pressure may cause severe injury. Always wear safety glasses.
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your KING COBRA-1200 PRO 240V for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts.
  • Page 4 Record the serial number and model of your new extractor here: (and be sure to mail your warranty card) Serial Number: __________________ Model: KING COBRA-1200 PRO 240V. Purchase Date:_____________ Write the name and phone number of your distributor: _____________________________________ SWITCH PLATE...
  • Page 5 OPERATION REFER TO THE DIAGRAMS ON THE PREVIOUS PAGE HIGH PRESSURE WASHER Before each use, inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Make sure hoses are in good condition and the spray nozzle(s) is tight. REFER TO THE AUTO-FILL AND AUTO-DUMP INSTRUCTIONS ON THE FOLLOWING PAGES 2.
  • Page 6 LOW PRESSURE AND HEAT Before each use, inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Make sure hoses are in good condition and the spray nozzle(s) is tight. REFER TO THE AUTO FILL AND AUTO-DUMP INSTRUCTIONS ON THE FOLLOWING PAGE 2.
  • Page 7 USING THE AUTO-FILL AND/OR AUTO-DUMP FEATURES AUTO-FILL Chemical Supply: • Place the container of concentrated chemical cleaner -- use a product with a pH between 7 and 9 to avoid premature pump wear, which would void the warranty -- in the holder on top of the recovery tank. •...
  • Page 8 AUTO-DUMP Operation: Before each use: if necessary, unscrew the stainless steel filter inside the recovery tank and clean it. Also make sure the float in the recovery tank is clean. • Attach a 3/4” garden hose to the dump pump outlet fitting on the back of the base of the machine. Refer to illustration below.
  • Page 9 240V...

  • Page 10: Part List

    KING COBRA-1200 PRO PART LIST 240 V ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION TA-37C Hose, Chemical Pick-up, 54” Washer, flat, 5/16” Axle cap 1199 Check valve & filter Gasket, for vacuum 123 1105 Axle, 1/2” X 21” Wire tie, white,8”...

  • Page 11: Specifications

    SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Vacuum: 7.2” 3-stage VAC Shutoff: Ball Float Pump: Positive displacement, fully adjustable 0-500 psi & Positive displacement, 1200 psi, 2.2 gpm Waterlift: 140” Heat: Instant to 212 ºF Heater: 2000 Watts Wand: Stainless steel, single bend, twin tip Weight: 170 lbs.
  • Page 12 KC-1200 PRO 240V DUAL SURFACE EXTRACTOR NOTES: 800-257-7982 • 208-772-0573 • FAX: 208-772-0577 Coeur d’Alene, Idaho VISIT US AT: http://www.usproducts.com...
