U.S. Products COBRA-C1 Information & Operating Instructions

Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
COBRA
-C1
®
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THE INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. Use the machine indoors. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
6. Never use water above 130 ºF/54 ºC in the solution tank.
3-5-2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the COBRA-C1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U.S. Products COBRA-C1

Summary of Contents for U.S. Products COBRA-C1

  • Page 1 COBRA ® EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage. 2.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.

  • Page 3: Cleaning Solutions

    INSPECTION: Carefully unpack and inspect your COBRA-C1 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts.

  • Page 4: Switch Plate

    SWITCH PLATE 1 = VACUUM ON/OFF SWITCH 2 = PUMP ON/OFF SWITCH COBRA-C1 SWITCH PLATE LID (RECOVERY TANK) HOLDING TANK LID VAC INTAKE LATCH (2) WHEEL DRAIN VALVE VENT QUICK-DISCONNECT CASTOR...

  • Page 5: Operation

    Refer to the drawings on the previous page OPERATION Inspect the machine, hoses, and cleaning tools for cleanliness and completeness. Fill the solution tank with water. Using warm water may be a benefit in cleaning effectiveness, but do not use hot water (above 130 ° F / 54 ° C) in the tank. Plug in the power cord.
  • Page 7 COBRA-C1 PART LIST 120V ITEM PART DESCRIPTION ITEM PART DESCRIPTION 2003 Wheel, 8" Drain gate Axle Cap Screw, 8-32 X 5/8" Lock nut, 1/4-20 Latch Axle bracket O-Ring Bolt, 1/4-20 X 3/4" 187B Washer, rubber BS-6 Base, black Nut, Aluminum, 1-1/2"...
  • Page 8 COBRA-C1 EXTRACTOR 120V TROUBLESHOOTING: ALWAYS UNPLUG THE MACHINE BEFORE DISCONNECTING OR CONNECTING ANY WIRES OR COMPONENTS IF THIS CHECK THIS Solution tank is empty. NO SPRAY Clogged spray tip. Pump not running. Valve on wand not operating PUMP DOES No power to pump. Test the switch. Test the pump motor. Replace if necessary.
