U.S. Products SOLUS-150 Information & Operating Instructions

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SOLUS-150
EXTRACTOR
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THIS INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Keep machine from rain and snow, extremes in temperatures, and store in a
heated location. DO NOT let the machine freeze. Do not use outdoors.
3. Do not let the pump run dry.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
6. Never use water above 130 ºF/54 ºC in the solution tank.
5.20.2008
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOLUS-150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for U.S. Products SOLUS-150

Summary of Contents for U.S. Products SOLUS-150

  • Page 1 SOLUS-150 EXTRACTOR 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THIS INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: NOTE: Read all instructions before using this machine.
  • Page 3 INSPECTION: Carefully unpack and inspect your SOLUS-150 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts CLEANING SOLUTIONS: We recommend liquid cleaning chemicals, such as our Magic Fabric Cleaner.
  • Page 4 SWITCH PLATE SOLUS-150 VACUUM SWITCH (1): This switch will illuminate when the vacuum motors are on. The vacuum motors run off of cord #1. HEAT SWITCH (2): The heat switch will illuminate when it is activated and will turn the heater on.
  • Page 5 SET-UP: 1. Fill the holding tank with clear water and prespray with the detergent of your choice (we recommend a CRI approved chemical). Mix well. Although this machine is designed to supply instant hot water, the addition of warm water to the holding tank would increase heater efficiency. Never use water above 130º F/54º C in the solution tank. 2.
  • Page 6 Pump to Heater Hose Heater to Outlet Hose SOLUS-150 05.20.2008 05.20.2008...

  • Page 7: Part List

    SOLUS-150 EXTRACTOR PART LIST 120V ITEM PART No DESCRIPTION ITEM PART No. DESCRIPTION FP312 Switch, SPDT 1062 Receptacle, AC power in Light, green indicator Hinge pin Light, red, indicator Axle FP311A Switch, SPST, with cover Axle Cap 2093D Switch plate, Solus 150 2092 Wheel, 12”...

  • Page 8: Trouble Shooting

    SOLUS-150 TROUBLE SHOOTING: IF THIS OCCURS CHECK THIS Solution tank is empty, or filter is plugged up. NO SPRAY Clogged spray tip. Pump not running. Valve on wand not operating. Solution hose not completely connected to hose or to machine.
