Wyrestorm EXP-SW-0301 Quick Start Manual page 4

Specifications
Audio and Video
Inputs
Outputs
Output Video Encoding
Audio Formats
Video Resolutions (Max)
Color Depth
Maximum Pixel Clock
Communication and Control
HDMI
IR
Power
Power Supply
Max Power Consumption
Environmental
Operating Temperature
Storage Temperature
Maximum BTU
Dimensions and Weight
Rack Units/Wall Box
Height
Width
Depth
Weight
Regulatory
Safety and Emission
Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice.
Copyright © 2019 WyreStorm Technologies |
EXP-SW-0301 Quickstart Guide | 190927
Version 1
3x HDMI In: 19-pin type A
1x HDMI Out: 19-pin type A
HDMI TMDS
2ch PCM | Dolby Digital True HD | DTS-HD Master Audio
1920x1080p @60Hz 8bit (15m/49ft)
1920x1200p @60Hz 8bit (15m/49ft)
8bit
297MHz
HDMI | HDCP 1.4
1x Front Panel Sensor
5V DC 1A (External Power Supply)
4W
0 to + 45°C (32 to + 113 °F),
10% to 90%, non-condensing
-20 to +70°C (-4 to + 158 °F),
10% to 90%, non-condensing
13.64 BTU/hr
<1U
19mm/0.75in
120mm/4.73in
69mm/2.72in
0.7kg/1.54lbs
CE | FCC | RoHS
wyrestorm.com
Version 2
3x HDMI In: 19-pin type A
1x HDMI Out: 19-pin type A
HDMI TMDS
2ch PCM | Dolby Digital True HD | DTS-HD Master Audio
1920x1080p @60Hz 8bit (15m/49ft)
1920x1200p @60Hz 8bit (15m/49ft)
3840x2160p @30Hz 4:4:4 8bit (7m/23ft)
4096x2160p @60Hz 4:2:0 8bit (7m/23ft)
8bit
297MHz
HDMI | HDCP 2.2
1x Front Panel Sensor | 1x IR Ext: 3.5mm (1/8in) TRS Stereo
5V DC 1A (HDMI In | External Power Supply)
.25W
0 to + 45°C (32 to + 113 °F),
10% to 90%, non-condensing
-20 to +70°C (-4 to + 158 °F),
10% to 90%, non-condensing
0.85 BTU/hr
<1U
21mm/0.83in
137mm/5.39in
70.2mm/2.76in
0.26kg/0.57lbs
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
4 of 4
