MANUAL
OPERATION
READ THIS MANUAL CAREFULLY FOR INSTRUCTIONS ON CORRECT
INSTALLATION AND USAGE, AND READ ALL SAFEGUARDS.
~
'
SECCION EN ESPANOL
SECTION EN FRANÇAIS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PC7 and is the answer not in the manual?

Questions and answers

Summary of Contents for Movincool PC7

  • Page 1 MANUAL OPERATION READ THIS MANUAL CAREFULLY FOR INSTRUCTIONS ON CORRECT INSTALLATION AND USAGE, AND READ ALL SAFEGUARDS. ‘ SECCION EN ESPANOL SECTION EN FRANÇAIS...
  • Page 2: Table Of Contents

    Foreword Congratulations on purchasing the MovinCool portable air conditioner. This manual explains how to install and operate the MovinCool PC7 portable air conditioning unit. Please read this operation manual thoroughly to familiarize yourself with the features of the unit and to ensure years of reliable operation.
  • Page 3 INTRODUCTION MOBILE AIR CONDITIONER The PC7 is a small appliance,which can adjust the temperature and humidity in a room making it easy to use in different occasions. It also has multiple modes, including cooling, dehumidifying and fan only. This unit was designed to be used in a family house, office, etc.
  • Page 4: Unit Description And Function

    UNIT DESCRIPTION AND FUNCTION FRONT control panel up/down air swinging fins air oulet handle left/right air swinging fins water tank cable (power caster cord and plug) BACK evaporator air inlet grill hot air outlet grill condenser air inlet grill...
  • Page 5 UNIT DESCRIPTION AND FUNCTION TIMER Button SWING Button FAN SPEED Button MODE Button Press this button to set the Pressing this button will Pressing this button Pressing this button cycle through cooling, timer for switch-on,switch- will activate/deactivate will cycle through high, drying, or fan-only mode off or to stop the timer.
  • Page 6: Operation Of Remote Control

    OPERATION OF REMOTE CONTROL Display screen ON/OFF Button Temperature setting button Pressing this button will turn the machine This button is used to set the ON or OFF. HEAT room temperature,Each COOL DRY FAN pressing of the" " or " "...
  • Page 7 POWER SOURCE *The AC socket must secured and in good condition *Do not connect the PC7 to an outlet which is also being used for other electrical equipment. *Fully insert plug into A/C outlet, * The unit will beep for 2 seconds.
  • Page 8: Use Of Control Panel

    USE OF CONTROL PANEL TIME SET FUNCTION To set start time, while the machine is turned off (but power supplied), press" " button, the LCD window will show " ", press the TIME button to set the start time. The setting range is 1-12 hours.
  • Page 9 WATER DRAINAGE METHODS f i g . 2 f i g . 3 CAUTION 1. When in cooling or dehumidifying mode, do not take out the condensate tank,or the buzzer will sound, the compressor will stop, and the mode will change to FAN. 2.
  • Page 10: Maintenance/Service

    *Unplug the unit before cleaning to prevent accidents caused by electric shock. *Do not use chemical solvent ( like benzene, alcohol glazer) to clean the surface of the unit. The surface of the PC7 will be scratched,damaged,and plastic casing can become deformed.
  • Page 11 MAINTENANCE/SERVICE CLEANING SURFACE Clean the surface of the unit with a damp cloth, then dry using a duster or similar type of lint-free cloth. WATER TANK 1. Slowly pull condensate tank away from unit 2. Empty water, clean dirt with neutral detergent, wash and dry 3.
  • Page 12: Storage Methods

    STORAGE METHODS END OF SEASON OPERATIONS 1. Remove condensate drain tank from unit 2. Locate plastic tube as shown in Fig. 4. Remove plug and operate the unit in fan mode for half a day or until tube is dry. 3.
  • Page 13: Safety Cautions

    * Do not cover the air outlet to avoid overheating. Maintain 20" clearance from openings SERIOUS CAUTION *Do not tip over or incline the PC7, If the unit does tip over please unplug at once and call your nearest reseller for further directions.
  • Page 14: Troubleshooting

    1. The fuse and circuit breaker trip often. 2. The power cord is hot or the sleeve of the cord broken. Self diagnosis function The PC7 is equiped with self-diagnostic codes to assist users in troubleshooting the unit. Please see the following chart below Check code...
  • Page 15: Installation

    INSTALLATION Selection of installation lacation Put the mobile air conditioner in a flat location where the air outlets cannot be obstructed, place the unit no less than 20" away from a wall or other obstacles. 830mm(327 inch) The air exhaust duct mounting method 1) Fix the square end of the exhaust dust to the exhaust terminal of the unit 2) Put the other end(discharge) to the nearest window Note: Exhaust length is between 24 in - 71in,...
  • Page 16 INSTALLATION Recommended exhaust mounting is shown below (If mounting in the wall,the height of the hole should be 16in ~ 51in) fig. 23 (51 inch) (16 inch) If the air exhaust requires bends, see diagrams below. (20 inch) (24 inch) (20 inch)
  • Page 17: Window Kit Installation

    INSTALLATION See diagram below for incorrect exhaust mounting (Air exhaust bends too large) Window Kit Installation Your window kit has been designed to fit most standard "vertical" and "horizontal" windows However, it may be necessary for you to modify some aspects of the window panels for certain types of windows.
  • Page 18 INSTALLATION Installation Accessories Fig. 25 Description Fig. 25 Flexible exhaust hose with adapters...3/set streches from 19 1/2" (50 cm) up to 78 3/4"(200cm) Window exhaust adapter (flat mouth )..1pc Adjustable window slider kit......2/set from 26 5/8" (67.5 cm) up to 48 3/8"...
  • Page 19 AFCI / LCDI Power Cord Manual WARNING The AFCI / LCDI device is a non-serviceable part. Attempting to open the device may expose the user to hazardous electric shock, and voids any warranties and performance claims. Manufacturer’s liability is limited to the replacement of the device.
