ISDT D2 Mark II User Manual page 6

Specifications
Input:
Charge Current:
Discharge Current:
Max Charge Power:
Max Discharge Power:
Max Balance Current:
Balance Cells:
USB Port:
Supported Batt. Type:
Display:
Operating Temperature:
Storage Temperature:
Dimensions:
Weight:
Accessory:
AC 100~240V
0.2~12.0A × 2
0.1~1.5A × 2
200W
15W × 2
1.5A/cell
2~6S × 2
5V/2A
LiPo/LiHv/LiFe/Lilon (1~6S)
NiMH/Cd (1~16S)
Pb (1~12S)
2.4" 320×240 IPS LCD
0~40°C
-20~60°C
120×108×70 mm
558g
AC input cable
1
2
3
1. AC input
2. USB port
3. Update port
4. Balance port for CH 1
5. Battery port for CH 1
6. Battery port for CH 2
7. Balance port for CH 2
11
10
9
8
6
5
4
8. CH 1 select button
9. CH 2 select button
10. 2.4"IPS display
11. Speed shuttle key
7
