14
en | Description
5
Description
The UML-202-90 20-inch (51-cm) Color Panel Display Monitor displays PAL or NTSC standard
color pictures in CCTV systems. The UML-202-90 monitor includes two (2) looping Composite
Video BNC connector inputs, two (2) looping Audio input RCA, and two (2) looping Y/C (S-
Video) input using a 4-pin mini-DIN. In addition, this model also includes an Analog VGA input
using 15-pin D-sub to accommodate the increasing use of PCs and digital video devices in
security applications, an HDMI (High Definition Multimedia Input), DVI, PC-RGB (VGA), RC
Audio In and Out, and Component Video (Y/Pb/Pr) connectors.
Monitor control functions are accessed via the front panel push buttons and On-screen Dis-
play (OSD). See Figure 3.1 on page 10 for front panel descriptions.
5.1
Features
This high-performance, 20-inch Color Panel Display Monitor with 1600 X 1200 pixels resolu-
tion has been designed to display Analog VGA and Composite Video signals.
–
–
–
–
–
–
–
5.2
Power
Model No.
UML-202-90
F01U076723 | 1.0 | 2007.09
90 to 256 VAC Power Supply
NTSC/PAL Auto-Detect
1600 x 1200 High-Resolution Display
VGA Input
Composite Video Input
Y/C Input (S-Video)
On-screen Display (OSD) with Multiple Languages
Rated Voltage
120/230 VAC
50/60 Hz
Instruction Manual
Voltage Range
Power at Rated Voltage Sync Format
90 to 256 V
70 W (max)
UML -202-90
NTSC/PAL
Bosch Security Systems, Inc.
