Summary of Contents for Bosch UML-172-90
- Page 1 High Performance LCD Monitors UML-172-90 | UML-192-90 | UML-202-90 User’s Manual...
-
Page 3: Table Of Contents
Single / Multiple Monitor Configuration Navigating the Monitor Navigating the Front Panel Navigating the Monitor On-screen Display (OSD) On-screen Display Menus Custom Menu Picture / Sound Menu PIP Menu Setup Menu Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03... - Page 4 | Table of Contents High Performance LCD Monitors Power Management Power Consumption LED Indicator TroubleShooting Guide Maintenance Technical Specifications F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc.
-
Page 5: Safety
ON/OFF switch is in the ON position. The power cord is the main power disconnect device for switching off the voltage for all units. Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03... - Page 6 17. Attachments, changes or modifications - Only use attachments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.
-
Page 7: Safety Precautions
Connect outdoor equipment to the unit's inputs only after this unit has had its grounding plug connected to a grounded outlet or its ground terminal is properly connected to a ground source. Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03... - Page 8 Please dispose of these units at an environmentally compatible recycling facility, per European Directive 2002/96/EC. Environmental statement - Bosch has a strong commitment towards the environment. This unit has been designed to respect the environment as much as possible.
- Page 9 Because the ISDN circuits are treated like telephone-network voltage, avoid connecting the SELV circuit to the Telephone Network Voltage (TNV) circuits. Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of lost digital information, Bosch Security Systems recommends multiple, redundant recording systems, and a procedure to back up all analog and digital information.
- Page 10 60950-1. UL Certification does not cover the performance or reliability of the security or signaling aspects of this product. UL MAKES NO REPRESENTATIONS, WARRANTIES, OR CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING-RELATED FUNCTIONS OF THIS PRODUCT. F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc.
- Page 11 High Performance LCD Monitors Safety | en Copyright This user guide is the intellectual property of Bosch Security Systems, Inc. and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.
-
Page 12: Customer Support And Service
| Safety High Performance LCD Monitors Customer Support and Service If this unit needs service, contact the nearest Bosch Security Systems Service Center for authorization to return and shipping instructions. Service Centers Telephone: 800-366-2283 or 585-340-4162 Fax: 800-366-1329 Email: cctv.repair@us.bosch.com... -
Page 13: Unpacking
Verify that all the parts listed in the Parts List below are included. If any items are missing, notify your Bosch Security Systems Sales or Customer Service Representative. The original packing carton is the safest container in which to transport the unit and must be used if returning the unit for service. -
Page 14: Exploded View
Increases the value when in the Scrolls right in the OSD IR Sensor Remote control sensor LED Indicator Power On (green) Power Off, Standby (red) Power Button Display Power (On/Off) F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc. - Page 15 Component Y, Pb, Pr and Sound L, R Audio IN (AV1, S-Video) DC 12 V IN Audio OUT (AV1, S-Video) Audio IN (AV2) Audio OUT (AV2) 12 V Adaptor Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03...
-
Page 16: Remote Control
| Remote Control High Performance LCD Monitors Remote Control This section details the functions and the usage of the Bosch remote control. Button Function POWER Turns the power ON and OFF. SOURCE Selects the PC or Video source. Numbers Numerals 0-9. -
Page 17: Remote Control Battery Installation
Description The Bosch High Performance Family of LCD monitors display PAL or NTSC standard color pictures in CCTV systems. Two (2) looping Composite Video BNC connector inputs, two (2) looping Audio input RCA, and two (2) looping Y/C (S-Video) inputs using a 4-pin mini-DIN are included. -
Page 18: Power
To prevent overheating, ensure that the ventilation openings on the rear of the monitor are not covered. Mounting the Monitor The UML-172-90, UML-192-90, and the UML-202-90 are designed for use on a desktop or mounted to a wall or rack. 6.2.1... -
Page 19: Wall Mount Installation
Installing the Monitor | en 6.2.2 Wall Mount Installation The square mounting holes (100 mm [3.9 in.] centers) are compatible with the Bosch UMM- LW-20B fixed wall mount or the UMM-LW-30B swivel/tilt mount. Figure 6.1 Mounting the Device Connecting the Composite Video Signal to the Monitor There are two (2) BNC connectors located on the rear side panel of the monitor for composite video input and two (2) BNC connectors for composite video outputs (see Figure 3.3). -
Page 20: Connecting Audio To The Monitor
Red Video Red Ground Ground Green Video Green Ground SDA (for DDC) Blue Video Blue Ground H-Sync or H+V Sync Ground V-Sync Ground Signal Cable Detect SCL (for DDC) F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc. -
Page 21: Single / Multiple Monitor Configuration
Reference Description Video Camera VIDEO 2 (AV2) IN VIDEO 2 (AV2) OUT Figure 6.7 Multiple Monitor Configuration Reference Description Video Camera VIDEO 2 (AV2) IN VIDEO 2 (AV2) OUT Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03... -
Page 22: Navigating The Monitor
If required, press the Input button until a signal is displayed. NOTE: Menus are not available without a signal applied. Press the Power button to turn on the unit (see Figure 3.1 or Figure 3.2). F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc. -
Page 23: On-Screen Display Menus
Menu button to save any changes, then press the Menu button again to exit the OSD. Custom Brightness Contrast Color Tint Sharpness :Move :Input :Menu Table 7.1 Custom Menu (Video Mode) Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03... -
Page 24: Picture / Sound Menu
Picture / Sound submenu. Picture / Sound Picture Mode Custom Color Tone Normal Mute Volume Size 3D Comb :Move :Input :Menu Table 7.3 Picture / Sound Menu (Video Mode) F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc. - Page 25 Auto Adjust: Auto synchronizes screen to graphics adaptor. Manual choices are: Phase (range 0-100), H-Position (range 0-100), V- Position (range 0-100), Frequency (range 0-100). 3D Comb Enables or disables the 3D comb filter. Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03...
-
Page 26: Pip Menu
Setup icon. Press the up and down arrows to select the Setup submenu. Setup Reset Language English OSD Tone Blue Blue Screen Key Lock Firmware Version :Move :Input :Menu Table 7.6 Setup Menu F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc. -
Page 27: Power Management
Screen blanks after idle time and some electronic circuits or all circuitry in the monitor shuts down. SUSPEND ACTIVE OFF UNSUPPORTED MODE Green Normal operation but the screen displays an error message. POWER OFF Not operational. Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03... -
Page 28: Troubleshooting Guide
640 x 480; 60/72/75 Hz 800 x 600; 60/72/75 Hz 1024 x 768; 60/70/75 Hz 1280 x 1024; 60 Hz 1600 x 1200; 60 Hz F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc. -
Page 29: Maintenance
Ketone type materials – Ethyl alcohol – Ethyl acid – Toluene – Methyl chloride – Ammonia Use of these materials may permanently damage the polarizer due to a chemical reaction. Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03... -
Page 30: Technical Specifications
50,000 hours, at 50% brightness hours, at 50% brightness LCD Panel Optical Characteristics Luminance 300 cd/m, hard-coating (3H), non-glare treatment Contrast Ratio (CR) 1000:1 800:1 800:1 Viewing Angle 160°/160° 160°/160° 178°/178° (Horizontal/Vertical) F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc. - Page 31 Selects Video 1, Video 2, S-video, RGB, DVI, or HDMI input Menu Selects on-screen display (OSD) Up arrow, Menu select Down arrow, Menu select Left arrow, decrease Right arrow, increase Power On/Off Front Panel Lockout Multiple push-button combination Bosch Security Systems, Inc. User’s Manual F.01U.075.713 | 1.0 | 2008.03...
- Page 32 Monitor Only 5.86 kg (12.9 lb) 6.36 kg (14.0 lb) 7.50 kg (16.5 lb) Monitor with Packaging 8.08 kg (17.8 lb) 8.58 kg (18.9 lb) 9.72 kg (21.5 lb) F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc.
- Page 33 Humidity 10%-95%, non-condensing Parts Included One (1) Bosch High Performance Color LCD Flat Panel Monitor One (1) VGA to VGA cable, One (1) DVI to DVI cable One (1) Remote Control Two (2), 3-wire power cords with a grounded plug: one (1) with a European/Continental plug type and one (1) with a U.S.
- Page 34 | Technical Specifications High Performance LCD Monitors F.01U.075.713 | 1.0 | 2008.03 User’s Manual Bosch Security Systems, Inc.
- Page 36 Phone: +65 6319 3450 Telephone +1 888-289-0096 Fax: +31 40 2577 330 Fax: +65 6319 3499 +1 585-223-9180 emea.securitysystems@bosch.com apr.securitysystems@bosch.com www.boschsecurity.com www.boschsecurity.com Email: security.sales@us.bosch.com www.boschsecurity.us © Bosch Security Systems, 2008; F.01U.075.713 | 1.0 | 2008.03; Data subject to change without notice.
