Rev. 12/9/2013
WL‐100 Wheel Kit (WL‐WK):
Units equipped with a wheel kit include 4 casters (2 swivel‐type and 2 rigid) and a detachable
handle.
A total of 8 "bulldog" couplers are welded to elements of the frame. These couplers provide the
means for attaching the casters to the table.
 Four bulldogs (see items 1‐4 in the diagram below) are attached to the frame in locations where the
casters cannot contact the ground. The casters must be secured to these bulldogs whenever the
table is in use.
                        DO NOT apply a load to the tabletop unless the casters are in the storage bulldogs.

 The other bulldogs (items 5‐8) are attached to the frame in locations where the casters will contact
the ground when the table is lowered (see FIG. 3 on p. 2).
 Casters are pinned to the bulldogs with
in a particular bulldog, remove the hairpin clip from the end of the clevis pin and then remove the
clevis pin from the bulldog. Place the mounting bracket of the caster within the bulldog; then
reinsert the clevis pin and secure it in place by inserting a hairpin clip through the hole in the end of
the clevis.


Swivel caster (GFN‐4/2.5)













Detachable

FIG. 1: Locations of bulldogs
handle



















Copyright 2013 Vestil Manufacturing Co.

3
/
in. x 4
8
Rigid caster (GFN‐4/2‐R)

6

5
/
in. clevis pins and hairpin clips. To secure a caster
8
3
5
/
in. x 4
/
in. clevis pin
8
8
    Hairpin clip




3
4
7
8

WL‐WK, Manual



Swivel casters:
 Store in bulldogs 3 & 4;
 Attach to bulldogs 7 &
8 to move table.

Rigid casters:
 Store in bulldogs 1 & 2;
 Attach to bulldogs 5&6
to move table.

Page 1 of 2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WL-WK and is the answer not in the manual?

Questions and answers

Summary of Contents for Vestil WL-WK

  • Page 1           Swivel casters:     Store in bulldogs 3 & 4;     Attach to bulldogs 7 &    8 to move table.       Rigid casters:     Store in bulldogs 1 & 2;  1     Attach to bulldogs 5&6    to move table.  2          5                                        Copyright 2013 Vestil Manufacturing Co.    Page 1 of 2   ...
  • Page 2 (3 & 4)  bulldogs (1 & 2)        Pin hole in  end of handle                                                           Each receiver has a spring pin as shown in FIG. 2B. A loop of  FIG. 2B: Receiver and spring pin cable connects the pins. One side of the loop passes through a      small ring. To retract the spring pins, pull the ring away from  the table.  To install the handle, pull the ring to retract the spring pins;  insert the ends of the handle into the receivers; then release  Spring  the pins.  Align the pin holes in the ends of the handle with the  pin  Receiver spring pins to lock the handle into place.    FIG. 3: Casters in bulldogs 5‐8.  Swivel casters in  bulldogs 7 & 8  Rigid casters in bulldogs 5 & 6                                            NOTE: DO NOT move casters between bulldogs unless the maintenance props are deployed. The tabletop  must be securely supported by the props.  Copyright 2013 Vestil Manufacturing Co.    Page 2 of 2   ...
