LVB-2 Technical Specifications
INPUT
VOLTAGE
277V MAC through LLT Tester
PROBE L, N, GND, PH, PL

PROBE CONFIGURATION

PROBE HI - LINE
PROBE HI - PROBE LO
RESISTOR RANGE SPECIFICATION
7.5KΩ 300VAC / 20W / 2% +/- 100PPM
15KΩ
300VAC / 10W / 2% +/- 100PPM
30KΩ
300VAC / 5W / 2% +/- 100PPM
150KΩ
300VAC / 2W / 2% +/- 100PPM
350KΩ 300VAC / 0.5W / 2% +/- 100PPM
1.47MΩ
300VAC / 0.25W / 2% +/- 100PPM
2.97MΩ
300VAC / 0.25W / 2% +/- 100PPM
6.37MΩ 300VAC / 0.25W / 2% +/- 100PPM
GENERAL
TEST POINTS TEST CONDITION
PASS 15kΩ 1. LLT: 132VAC, 10,000uA High Limit
2. Maximum Voltage 277VAC
3. Ground = Open, Neutral = Closed, Reverse = Off
FAIL 7.5kΩ 1. LLT: 132VAC, 10,000uA High Limit
2. Maximum Voltage 277VAC
3. Ground = Open, Neutral = Closed, Reverse = Off
PASS 30kΩ 1. LLT: 132VAC, 6000uA High Limit
2. Maximum Voltage 277VAC
3. Ground = Open, Neutral = Closed, Reverse = Off
FAIL 15kΩ 1. LLT: 132VAC, 6000uA High Limit
2. Maximum Voltage 277VAC
3. Ground = Open, Neutral = Closed, Reverse = Off
PASS 150kΩ 1. LLT: 132VAC, 2000uA High Limit
2. Maximum Voltage 277VAC
3. Ground = Open, Neutral = Closed, Reverse = Off
© Ikonix USA
GND - LINE

CONNECTOR TERMINAL

L, N, GND
AC Socket
PH, PL Alden Connector
PROBE CONFIGURATION SWITCH
ON/OFF by 10A power switch
ON/OFF by 10A power switch
ON/OFF by 10A power switch
Note: Only one switch can be CLOSED at a time
SPECIFICATION
2%
2%
2%
2%
2%
LVB-2 Instruction Sheet
RESISTOR RANGE SWITCH
Select by Rotary Switch
