Summary of Contents for Ross Vision Squeeze & Tease
- Page 1 Ross Video Limited Squeeze & Tease Installation Guide...
- Page 2 Notice The material in this guide is furnished for informational use only. It is subject to change without notice and should not be construed as commitment by Ross Video Limited. Ross Video Limited assumes no responsibility or liability for errors or inaccuracies that may appear in this guide.
-
Page 3: Environmental Information
To avoid the potential release of those substances into the environment and to diminish the need for the extraction of natural resources, Ross Video encourages you to use the appropriate take-back systems. These systems will reuse or recycle most of the materials from your end-of-life equipment in an environmentally friendly and health conscious manner. -
Page 4: Package Contents
Package Contents The contents of the Squeeze & Tease™ upgrade kit depends on the number of Squeeze & Tease MD channels you are installing. If any items are missing, or damaged, contact Ross Video Technical Support. Part# Item 4800AR-047A Squeeze & Tease MD Carrier Board... - Page 5 Squeeze & Tease Overview The Squeeze & Tease™ MD option consists of a carrier board and a number of daughter cards that are installed into the frame. In order to install the Squeeze & Tease MD option, you must upgrade the switcher software, install the daughter cards onto the Squeeze &...
-
Page 6: Software Upgrade
Software Upgrade When a new board is installed, the switcher checks the current version of software on the board. If the software on the board is the same as the software on the switcher, there is no change. If the board has a software version that is different than the version on the switcher, the switcher will upgrade the board to the same version as the switcher. - Page 7 S&T MD Channel Card Installation Use the following procedure to install a Squeeze & Tease MD Card onto the Squeeze & Tease Carrier Board: Place the Squeeze & Tease Carrier Board on a clean, static-free surface. Locate the Squeeze & Tease MD Channel Card Slot (MD Slots 1 through 4) on the Squeeze &...
- Page 8 Squeeze & Tease MD Cards MD Slot 4 MD Slot 3 MD Slot 2 MD Slot 1 Connectors WARP Slot 2 WARP Slot 1 Squeeze & Tease WARP Squeeze & Tease WARP MD Card MD Card Figure 1 Squeeze & Tease Carrier Board — Daughter Card Slots Align the Squeeze &...
- Page 9 S&T WARP MD Card Installation Use the following procedure to install a Squeeze & Tease MD WARP Card onto the Squeeze & Tease Carrier Board: Place the Squeeze & Tease Carrier Board on a clean, static-free surface. Locate the Squeeze & Tease WARP MD Slot (WARP Slots 1 and 2) on the Squeeze &...
- Page 10 Squeeze & Tease MD Cards MD Slot 4 MD Slot 3 MD Slot 2 MD Slot 1 Connectors WARP Slot 2 WARP Slot 1 Squeeze & Tease WARP Squeeze & Tease WARP MD Card MD Card Figure 3 Squeeze & Tease Carrier Board — Daughter Card Slots Align the Squeeze &...
- Page 11 Notes S&T WARP MD Card Installation • 11...
- Page 12 613 • 349 • 0006 613 • 652 • 4425 General Information solutions@rossvideo.com E-MAIL Technical Support techsupport@rossvideo.com 8 John Street, Ross Video Limited Iroquois, Ontario, Canada K0E 1K0 POSTAL SERVICE P.O. Box 880, Ross Video Incorporated Ogdensburg, New York, USA...
