- Page 1 Ultra 60 Configuration Guide v9.1...
-
Page 2: Document Information
7,602,446; US 7,802,802 B2; US 7,834,886; US 7,914,332; US 8,307,284; US 8,407,374 B2; US 8,499,019 B2; US 8,519,949 B2; US 8,743,292 B2; US D752,530 S; GB 2,419,119 B; GB 2,447,380 B; and other patents pending. ii • Document Information — Ultra 60 Configuration Guide (v9.1) -
Page 3: Table Of Contents
Extended Warranty..........15 Frame..................15 Ultra 60 Frame (CUF3-112)........15 Frame Dimensions.........36 Power Supplies............15 Ultra 60 Frame................36 Additional I/O Boards..........16 1RU Audio Breakout Unit Dimensions.........36 Extended Warranty..........16 Optional Hardware..............16 1RU Audio Breakout Unit (ABU)......16 Ultritouch..............16 Ultra 60 Configuration Guide (v9.1) — Contents • iii... - Page 4 TouchDrive Desk Cutouts......37 TD1C..................37 TD1...................38 TD2...................38 TD2S..................39 TD3S..................39 TD3/TDx3................40 TD4/TDx4................40 iv • Contents — Ultra 60 Configuration Guide (v9.1)
- Page 5 Key members of the design teams are part of an ongoing program in which they provide product demonstrations, assist with product installation, Ultra 60 Configuration Guide (v9.1) — Ultra 60 • 5...
-
Page 6: Features
You can change the processing order of the EQ and CL. for later airing without call-in phone numbers inserted. The clean feed can be set to include any keys for an ME. This allows you to remove particular 6 • Features — Ultra 60 Configuration Guide (v9.1) -
Page 7: Expandable I/O
2D effects to perform 2D Expandable I/O background transitions. Ultra 60 is the first in the Carbonite family to 3D Borders offer expandable I/O by installing up to two Flat or bevelled borders with independent inner Ultra 60 I/O boards. -
Page 8: Liveedl
, and Canvas comes standard graphics interface. with all switchers. All of these memories can be stored to a USB media drive, providing custom tailored memories for every operator and every show. 8 • Features — Ultra 60 Configuration Guide (v9.1) -
Page 9: Minime
SDR and HDR ranges and MultiViewer by pressing the SHIFT button on a between color gamuts (WCG). control panel or in ViewControl. The Ultra 60 Configuration Guide (v9.1) — Features • 9... -
Page 10: Viewcontrol
RPM licenses can easily be requested or released MultiViewer boxes, expanding the number of from a switcher to a pool of licenses on the Ross sources available on ViewControl from 16 to 32. Platform Manager. This allows you to move... - Page 11 Each switcher comes with a single license of XPression. Additional licenses can be ordered. ® ® Note: A separate Windows PC with an NVIDIA graphics card is required to use this option. PC no provided. Ultra 60 Configuration Guide (v9.1) — Features • 11...
-
Page 12: Product Comparison
Compatible Ethernet 1 × 2.5GigE Connectivity Roll Clip Control AMP/RossTalk/GPI Output 4 × USB 2.0, 1 × USB 3.0 Serial Ports ® ® Ethernet Serial Port Comtrol DeviceMaster Expanders Series 12 • Product Comparison — Ultra 60 Configuration Guide (v9.1) - Page 13 Channels 1,3,7 have access to the first block, 2,4,8 have access to the second, and 5,6 have access to the last. Only Media-Store channels 1 and 2 support audio. Ultra 60 Configuration Guide (v9.1) — Product Comparison • 13...
-
Page 14: Hardware Options
Option Description replaced with a Dual Delegation keyer row providing two rows of CUF-PSU Adds a brick power supply for the buttons. TouchDrive control panel. 14 • Hardware Options — Ultra 60 Configuration Guide (v9.1) -
Page 15: Extended Warranty
Adds an additional year of warranty to the TD4 control panel. CUF3-PSU Adds a second internal power supply module for the frame. TDx3-PANEL-HM Adds an additional year of warranty to the TDx3 control panel. Ultra 60 Configuration Guide (v9.1) — Hardware Options • 15... -
Page 16: Additional I/O Boards
The CUF3-ADD-I/O-BOARD-HW option adds an additional requirements. year of warranty to a single Ultra 60 I/O board. For example, if you have two Ultra 60 I/O boards and want to add two years Option Description of warranty to each, you must order 4 CUF3-ADD-I/O -BOARD-HW options. -
Page 17: Xpression Live Cg (Xds0-0001-Cps)
The SHC-9642 SDI to HDMI Converter is a great way to convert a 3Gb/s MultiViewer output to HDMI ™ for external monitoring. HD-BNC to BNC Adapters Option Description CUF-HDBNC-BNC 8 HD-BNC to BNC cable adapters. Ultra 60 Configuration Guide (v9.1) — Hardware Options • 17... -
Page 18: Software Options
™ MiniME MiniME Output 4 × 4 × 24 (16+8) × Input 2 × CUF3-ADD- 36 (24+12) UltraScene UltraScene I/OPLUS × Input 12 (8+4) × 12 (8+4) × Output Output 18 • Software Options — Ultra 60 Configuration Guide (v9.1) -
Page 19: Rave Audio Mixer
The MIDI controller is used to control the RAVE surpassed as well as how long after the level audio mixer through DashBoard. drops below the threshold that the compressor is still applied. Ultra 60 Configuration Guide (v9.1) — Software Options • 19... -
Page 20: Madi
Option Description SFP-MADI-COAX Embrionix EB06HDRT-MN-MADI, a medium reach electrical MADI Audio SFP (emSFP) transceiver module. SFP-MADI-850MM Embrionix GO2949-85CL, a short reach optic video SFP. 20 • Software Options — Ultra 60 Configuration Guide (v9.1) -
Page 21: Training And Commissioning Options
Two (2) days, or more, of advanced notice will incur full invoice. training is recommended for multiple ME systems. Four (4) weeks advanced scheduling Ultra 60 Configuration Guide (v9.1) — Training and Commissioning Options • 21... - Page 22 Contact your Ross representative to discuss which types of assistance are best suited to your needs. Option Description CARBONITE-COM-1DAY Add 1 Day of on-site commissioning. 22 • Training and Commissioning Options — Ultra 60 Configuration Guide (v9.1)
-
Page 23: Specifications
Media-Store Channels (Video + Alpha) Media-Store CACHE 12 GB Memories per ME Pattern Generators per ME Matte Generators per ME (1+ Global) UltraScene Scenes (Max) Sequencers (Max) Tallies SDI Video Inputs (Max) Ultra 60 Configuration Guide (v9.1) — Specifications • 23... -
Page 24: Hardware Weights
2,4,8 have access to the second; and 5,6 have access to the last. In UHDTV1, channels 1,3 have access to the first block; 2,4 have access to the second; and 5,6 have access to the last. The total number of Inputs and Outputs depends on the number of Ultra 60 I/O boards installed in the frame. -
Page 25: Video Input Specifications
<-19dB @ 1.5GHz 30ps ±10% (UHD) Rise and Fall Time 49ps ±10% (HD) 800mV ±10% Signal Level DC Offset <-7mV Overshoot <10% Video Outputs, SDI HD Mode 10-bit SMPTE-292M/424M serial digital Ultra 60 Configuration Guide (v9.1) — Specifications • 25... -
Page 26: Abu Analog Audio Input Specifications
Performance not guaranteed with composite reference UHD - Composite Reference HD - Tri-Level Sync Alignment (> 100KHz) < 0.1UI Timing (<10Hz) < 1.0UI Performance not guaranteed with composite reference HD - Composite Reference 26 • Specifications — Ultra 60 Configuration Guide (v9.1) -
Page 27: System Timing
AES Input — Left Channel AES Input — Right Channel unused unused Note: All embedded audio streams going to the 1RU Audio Breakout Unit pass through the hardware and are available on the SDI1 OUT. Ultra 60 Configuration Guide (v9.1) — Specifications • 27... - Page 28 Aux 12 Right ABU Analog 1-1 ABU Analog 1-2 ABU Analog 1-3 ABU Analog 1-4 ABU Analog 1-5 ABU Analog 1-6 ABU Analog 1-7 ABU Analog 1-8 ABU Analog 2-1 ABU Analog 2-2 28 • Specifications — Ultra 60 Configuration Guide (v9.1)
- Page 29 ABU Analog 3-5 ABU Analog 3-6 ABU Analog 3-7 ABU Analog 3-8 Media-Store 1 Channel 1 Media-Store 1 Channel 2 Media-Store 2 Channel 1 Media-Store 2 Channel 2 Clip Player Channel 1 Silence Ultra 60 Configuration Guide (v9.1) — Specifications • 29...
-
Page 30: Option Codes
1 × CUF3-ADD-I/OPLUS Extra I/O Processor (24/8 HD) Extra I/O Processor (36/12 HD) 2 × CUF3-ADD-I/OPLUS Extra I/O Processor (48/16 HD) 3 × CUF3-ADD-I/OPLUS Extra I/O Processor (60/20 HD) 4 × CUF3-ADD-I/OPLUS 30 • Option Codes — Ultra 60 Configuration Guide (v9.1) -
Page 31: Training Options
I/O Board Extended Warranty (1RU Audio GRAPHITE-1RU-ABU-12G-ROSSCARE Breakout Unit-12G) Training Options Code Carbonite Online Operational CARBONITE-ONL-1DAY Training Carbonite Onsite CARBONITE-COM-1DAY Commissioning Carbonite Onsite Operational CARBONITE-OTR-1DAY Training Carbonite Onsite Technical CARBONITE-OTT-1DAY Training Ultra 60 Configuration Guide (v9.1) — Option Codes • 31... -
Page 32: Panel Dimensions
Ross Video website. Dimensions are in inches with metric dimensions shown in brackets [mm]. TD1C Note: * Because the TouchDrive control panel is curved, the depth measurement is only approximate. 32 • Panel Dimensions — Ultra 60 Configuration Guide (v9.1) -
Page 33: Td2
* Because the TouchDrive control panel is curved, the depth measurement is only approximate. TD2S Note: * Because the TouchDrive control panel is curved, the depth measurement is only approximate. Ultra 60 Configuration Guide (v9.1) — Panel Dimensions • 33... -
Page 34: Td3S
* Because the TouchDrive control panel is curved, the depth measurement is only approximate. TD3/TDx3 Note: * Because the TouchDrive control panel is curved, the depth measurement is only approximate. 34 • Panel Dimensions — Ultra 60 Configuration Guide (v9.1) -
Page 35: Td4/Tdx4
TD4/TDx4 Note: * Because the TouchDrive control panel is curved, the depth measurement is only approximate. Ultra 60 Configuration Guide (v9.1) — Panel Dimensions • 35... -
Page 36: Frame Dimensions
Frame Dimensions Dimensions are in inches with metric dimensions shown in brackets [mm]. Ultra 60 Frame 1RU Audio Breakout Unit Dimensions 36 • Frame Dimensions — Ultra 60 Configuration Guide (v9.1) -
Page 37: Touchdrive Desk Cutouts
These dimensions are provided as a guide only. Scale DXF/CAD drawings of the control panels are available from the Ross Video website that should be used as a template for a desk cutout. Dimensions are in inches with metric dimensions shown in brackets [mm]. -
Page 38: Td1
Remove the on-desk legs from the bottom of the control panel to mount it in a desk. Note: Remove the on-desk legs from the bottom of the control panel to mount it in a desk. 38 • TouchDrive Desk Cutouts — Ultra 60 Configuration Guide (v9.1) -
Page 39: Td2S
Remove the on-desk legs from the bottom of the control panel to mount it in a desk. TD3S Note: Remove the on-desk legs from the bottom of the control panel to mount it in a desk. Ultra 60 Configuration Guide (v9.1) — TouchDrive Desk Cutouts • 39... -
Page 40: Td3/Tdx3
Remove the on-desk legs from the bottom of the control panel to mount it in a desk. TD4/TDx4 Note: Remove the on-desk legs from the bottom of the control panel to mount it in a desk. 40 • TouchDrive Desk Cutouts — Ultra 60 Configuration Guide (v9.1)
