Bogen Easy Design WB1EZ Specification

Easy Design
Wall Baffle Speaker
Model WB1EZ
The Bogen WB1EZ Wall Baffle Speaker is an 8" cone speaker enclosed in a simulated walnut-finished
wooden enclosure with a black grille cloth on front. The WB1EZ is a 1-watt single-tap speaker with
Description
recessed volume control designed for use in 70V amplifier systems.
Designed for easy wall-mount installation, the WB1EZ comes pre-assembled.
• Features screw terminal connections for fast
• 1W single-tap design
Features
• Works with 70V amplifier outputs
• High intelligibility and efficiency
Power Rating (RMS):
Frequency Response:
Technical
Impedance:
Specifications
Sound Pressure Level:
Dimensions:
Shipping Weight:
Finish:
The surface mounting loudspeaker shall be a
Bogen Model WB1EZ, or equivalent, 8" cone-type
loudspeaker having a frequency response of at
Architect
least 50 Hz to 12 kHz.The on axis sound pressure
and Engineer
level shall be 95 dB, at least four feet with one-watt
Specifications*
input. The loudspeaker shall have a six-ounce
ceramic magnet and a
The loudspeaker shall be assembled in a wall baffle
for surface-mounting, angled for additional down-
ward sound dispersion. The baffle shall be con-
structed of
* Architect and Engineer Specifications are available on CD and online
in a Word document to assist you with preparing your bids.
Specifications subject to change without notice.
© 1999 Bogen Communications, Inc.
Part No. 54-7886-01B Printed in U.S.A. 0303
™
wire lead connection
/ " voice coil.
3
4
/ " particle board, glued and covered in
3
8
• Simulated walnut vinyl finish
• Designed for easy wall-mount installation
• 8" cone speaker
• Wooden cabinet
• Recessed volume control
1-watt, continuous
50 Hz to 12 kHz
4900 ohms (for use on 70V amplifier outputs)
95 dB at 4 ft. with a 1-watt input on axis
9- / " W x 9- / " H x 5- / " D (3-
1 1 1
2 2 4
19 lb.
Simulated walnut vinyl
simulated walnut vinyl. Glue blocks shall be used to
reinforce all side corner joints. The speaker open-
ing shall be covered with a black grille cloth.
Overall dimensions shall be 9-
5- / " D [top] (3- / " D base).
1 1
4 4
