MACDEV DROID Owner's Manual page 10

Using a loader with your Droid
Your Droid Marker can operate using any commercially available loader.
The software and beam sensor will compensate for the speed of the hopper,
together ensuring that the marker fires as quickly as the loader allows.
All Droid markers are equipped with a cam lever clamping feed tube. This
system allows the easy installation and removal of your loader. You will need
to adjust the feed tube to suit the loader that you have.
Installing a loader onto your Droid
Open the cam lever as shown. This should allow your loader neck to fit into
the feed tube as shown. If your feed tube does not fit into the feed tube, then
you may have to loosen the adjustment screw slightly. Once your loader is
DO NOT OVER TIGHTEN YOUR FEED CLAMP! OVERTIGHTENING
MAY RESULT IN DAMAGE TO YOUR LOADER.
pushed all the way down into the feed tube, close the cam lever. If your loader
is loose, you may now tighten the adjustment screw (by turning clockwise) to
tighten the loader in place.
Removing your loader
Open the clamp by swinging the lever on its hinge. This will loosen the loader
and allow you to remove it easily. If it does not remove easily, then it means
that you have the clamp adjustment screw overtightened.
Insert of feed tubes and
loaders here
