How To Troubleshoot an Inoperable APsystems
A flashing red LED indicates the AC grid is either not present or not within specification.
The microinverter does not sense that the utility grid is within voltage/frequency
specifications, and cannot produce power until this is resolved. To troubleshoot an
inoperable APsystems microinverter, follow the steps in the order shown to diagnose
your solar system.
* WARNING: Risk of electric shock. Always de-energize the AC branch circuit before
servicing. Never disconnect the DC connectors under load.
* WARNING: The APsystems Microinverters are powered by DC power from the PV
modules. Make sure you disconnect the DC connections and reconnect DC power and
then watch for three green blinks after connection to DC power.
Troubleshooting an APsystems System - 15 Steps:
1.
Make sure AC breakers and disconnects are closed (off).
2.
Check the connection to the utility grid and verify that the utility voltage is within
allowable ranges.
Microinverter
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for APsystems APmicro YC600
Summary of Contents for APsystems APmicro YC600
- Page 1 * WARNING: Risk of electric shock. Always de-energize the AC branch circuit before servicing. Never disconnect the DC connectors under load. * WARNING: The APsystems Microinverters are powered by DC power from the PV modules. Make sure you disconnect the DC connections and reconnect DC power and then watch for three green blinks after connection to DC power.
- Page 2 106 to 132 VAC neutral neutral 5. Using an APsystems disconnect tool, disconnect the AC cable for the microinverter in question from the trunk cable. V erify that utility power is present at the microinverter by measuring line to line and line to neutral at the trunk cable connector.
- Page 3 PV module isn’t functioning correctly. If it stays in place, the problem is with the microinverter. Call APsystems Technical Support for help in reading the microinverter data and for help in obtaining a replacement microinverter, if needed.
