=> Max current 20.0A
Read manual first!
<< BACK <<
Select "Max current 20.0A" and set the desired
amperage limit. Confirm by pressing the PTK.
Max current 20.0A
Read manual first!
=> << BACK <<
Select << BACK <<.
Timer modes
Overcurrent
=> >> NEXT >>
Select >> NEXT >> to return to the main screen in a few
seconds.

5.12 Set 24-hour timer

You are in the main screen.
14:12:35 08-01-2015
No timer set!
Current 18.6A
Temp 21.6C
Press and hold the PTK for 6 seconds.
Set clock
=> Set Timers
Set temperature
>> NEXT >>
Select "Set Timers".
Set on and off time
On at 06:00
Off at 18:00
=> set Cancel
______________________________________________________________________________________________________________________________
TechGrow | Innovative Growing Solutions
Now you can set the switching times. Go to the next line
by pressing the PTK.
Put the cursor in front of "set" and save the settings.
From the main screen you can read the set times.
14:12:35 08-01-2015
On 06:00 Off 18:00
Current 18.6A
Temp 21.6C

5.13 Set "asymmetric" timer

Select the desired time clock and enter the main screen.
12:00:00 08-01-2015
No timer set!
Current 18.6A
Temp 21.6C
Press and hold the PTK for 6 seconds.
Set clock
=> Set Timers
Set temperature
>> NEXT >>
Select "Set Timers".
Set on and off time
On for 11:30
Off for 11:30
=> set Cancel
Set the "On" and "Off" period.
Put the cursor in front of "set" and save the settings.
The cycle in this example takes 2 x 11:30 hours = 23
hours.
ATTENTION: After saving the settings, the controller
always starts with the "On" period.
When the lights are on, you will see the next "Off" time,
followed by the "On" time.
