MACDEV CLONE Owner's Manual page 14

Symptom Possible Cause
The beam sensor is not Eyes are connected incorrectly
reading correctly
Eyes are faulty
MACDEV TECHNICAL ASSISTANCE
If you require technical assistance, please contact your local MacDev service centre. You can also find as-
sistance on the MacDev main website www.macdev.net, simply follow the prompts to the support page.
Alternatively, you can contact MacDev directly.
MacDev Australia
(Sydney, Australia)
Ph: +612 9531 5055
Fax: +612 9531 5188
Visit: www.macdev.net
Mail: info@macdev.net
Solution
Red/black wire eye is the left hand plug
Yellow/black wire eye is the centre plug.
Replace the eye pair.
CLONE RX SPECIFICATIONS
Physical
Length 216mm (524mm with barrel)
Width 35mm
Height 205mm
Weight 880g with barrel and battery
Barrel Threads Autococker
Performance
Operating pressure 100psi
Rate of Fire 30 BPS
Electronics
Software Militia Soft Version 1.0
Hardware Militia Version 1.0 (Lead Free)
Display OLED high visibility low power usage 96x16px
Power 9V standard battery 6LR61
Fire modes Semi, NXL, PSP, Response, Burst, Full Auto
Connectivity Mini USB
Solenoid 5V 1W
