barfield 2548H Instruction Supplement

Fuel quantity test set for cessna 402c s/n 0001 & on, 404 s/n 0001 & on, 414a s/n 0001 & on, 421c s/n 0114 & on
Hide thumbs Also See for 2548H:
1
2
3
4
5
6
7

Advertisement

Table of Contents

61-101-00435.A1
INSTRUCTION SUPPLEMENT
2548H FUEL QUANTITY TEST SET
P/N 101-00420
ADAPTER CABLE
P/N 101-00435
402C S/N 0001 & ON
404
S/N 0001 & ON
414A S/N 0001 & ON
421C S/N 0114 & ON
FOR
WITH
FOR
CESSNA
June 22, 1999

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 2548H and is the answer not in the manual?

Questions and answers

Related Manuals for barfield 2548H

Summary of Contents for barfield 2548H

  • Page 1 INSTRUCTION SUPPLEMENT 2548H FUEL QUANTITY TEST SET P/N 101-00420 WITH ADAPTER CABLE P/N 101-00435 CESSNA 402C S/N 0001 & ON S/N 0001 & ON 414A S/N 0001 & ON 421C S/N 0114 & ON 61-101-00435.A1 June 22, 1999...
  • Page 2 SYSTEM CAPACITANCE MEASUREMENT Remove power from Aircraft Fuel Quantity System. Defuel Aircraft as per Aircraft Maintenance Manual instructions. CAUTION: Observe all safety precautions. Gain access to the Signal Conditioner. Break electrical connection. Connect the Adapter Harness A/C connector to mating Aircraft wiring plug.
  • Page 3 SYSTEM INSULATION MEASUREMENT Remove power from Aircraft Fuel Quantity System. Defuel Aircraft as per Aircraft Maintenance Manual instructions. CAUTION: Observe all safety precautions. Gain access to the Signal Conditioner. Break electrical connection. Connect the Adapter Harness A/C connector to mating Aircraft wiring plug.
  • Page 4 Disconnect all connections. Return aircraft to normal configuration. SIGNAL CONDITIONER / INDICATOR TEST Remove power from Aircraft Fuel Quantity System. Gain access to the Signal Conditioner. Break electrical connection. Connect the Adapter Harness AUX connector to mating Aircraft wiring plug. Connect the Adapter Harness SIG.
  • Page 5 421C) or 93.6 pF (404). Depress and hold the COMP CAL pushbutton while varying the 0- 10 adjust knob to achieve the best null (as close to 0 µA as possible) on the Test Set meter. NOTE: Refer to Test Set manual for details. Release the pushbutton.
  • Page 6 PREFERRED CALIBRATION PROCEDURE Remove power from Aircraft Fuel Quantity System. Defuel Aircraft as per Aircraft Maintenance Manual instructions. CAUTION: Observe all safety precautions. Gain access to the Signal Conditioner. Break electrical connection. Connect the Adapter Harness AUX connector to mating Aircraft wiring plug.
  • Page 7 Set the TANK CAP pF thumbwheels to 55.9 pF for 100 grade fuel) 57.1 pF (for 100 octane low lead fuel) {402C, 414A, 421C} or to 44.0 pF for 100 grade fuel) 46.2 pF (for 100 octane low lead fuel {404}. Depress and hold the COMP CAL pushbutton while varying the 0- 10 adjust knob to achieve the best null (as close to 0 µA as possible) on the Test Set meter.
