Solar Inverter
TRIO-20.0/27.6-TL-OUTD
Quick Installation Guide
In addition to what is explained in this quick installation guide, the safety and installation information provided in the product manual must be read and
followed. The technical documentation for the product is available at the website.
The device must be used in the manner described in the manual. If this is not the case the safety devices guaranteed by the inverter might be
ineffective.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Fimer TRIO-20.0-TL-OUTD
Summary of Contents for Fimer TRIO-20.0-TL-OUTD
- Page 1 Solar Inverter TRIO-20.0/27.6-TL-OUTD Quick Installation Guide In addition to what is explained in this quick installation guide, the safety and installation information provided in the product manual must be read and followed. The technical documentation for the product is available at the website. The device must be used in the manner described in the manual.
- Page 2 -Reduction in the dielectric resistance of the air that, in the presence of high operating voltages (DC input), can create electric arcs (discharges) that can reach the point of damaging the inverter. All installations at altitudes of over 2000 metres must be assessed case by case with the FIMER Service department.
- Page 3 When you open the package, check that the equipment is undamaged and make sure all the components are present. If you find any defects or damage, stop unpacking and consult the carrier, and also promptly inform the Service FIMER. Weight of the equipment units...
- Page 4 6. List of supplied components Components available for all models Quantity Components available for all models Quantity Jumpers for configuration of the Connector for connecting the parallel input channels configurable relay Quick Installation Guide Connector for the connection of the communication L-key, TORX TX20 Additional components for (-S2F/-S2X) models...
- Page 5 300mA FIMER declares that the FIMER transformerless inverters, in terms of their construction, do not inject continuous ground fault currents and therefore there is no requirement that the differential protection installed downstream of the inverter be type B in accordance with IEC 60755 / A 2.
- Page 6 11. Output connection (AC) For the connection of the inverter to the grid, you can choose between a star connection (3 phases + neutral) and a delta connection (3 phases). WARNING – In any case, connection of the inverter to ground is mandatory. To prevent electrocution hazards, all the connection operations must be carried out with the disconnect switch downstream of the inverter (grid side) open and locked.
- Page 7 VoutRS XXXV details regarding use and functions available in the menu. *1 Available only for grid standard CEI-021 16. Characteristics and technical data TRIO-20.0-TL-OUTD TRIO-27.6-TL-OUTD Input Rated input DC power ( 20750 Wp 28600 Wp Pdcr Maximum Input Power (...
- Page 8 With regard to purchase orders, the agreed particulars reproduction, disclosure to third parties or utilization of representative or visit: shall prevail. FIMER does not accept any responsibility its contents – in whole or in parts – is forbidden without whatsoever for potential errors or possible lack of prior written consent of FIMER.
